LCD KVM Console (T1700/T1900)
User Guide
Release 1.1
Copyright © 2010 Raritan, Inc.
T1700_T1900-0E-v1.1-E
July 2010
255-37-0114-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T1900 and is the answer not in the manual?

Questions and answers

Related Manuals for Raritan T1900

Summary of Contents for Raritan T1900

  • Page 1 LCD KVM Console (T1700/T1900) User Guide Release 1.1 Copyright © 2010 Raritan, Inc. T1700_T1900-0E-v1.1-E July 2010 255-37-0114-00...
  • Page 2 This document contains proprietary informatio n that is protected by copyright. All rights reserved. No part of this document may be photocopied, reproduced, or translated into another language without express prior written consent of Raritan, Inc. © Copyright 2010 Raritan, Inc., CommandCenter®, Dominion®, Paragon® and the Raritan com pany logo are trademarks or registered trademarks of Raritan, Inc.

  • Page 3: Table Of Contents

    What the Warranty Does Not Cover ... v Safety Instructions ... vi Chapter 1 Introduction Package Content ... 1 T1700... 1 T1900... 1 Structure Diagram... 2 Chapter 2 Installation Before Installation ... 3 Rack-Mounting the LCD KVM Console ... 3 1.
  • Page 4 Contents How to Use the Slides... 18 Appendix A Standard Specifications Specifications... 20 Dimension ... 21 Appendix B Troubleshooting Index...

  • Page 5: Important Safeguards

    Important Safeguards Read all these instructions carefully before you use the device. Save this manual for future reference. What the Warranty Does Not Cover • Any product, on which the serial number has been defaced, modified or removed. • Damage, deterioration or malfunction resulting from: •...

  • Page 6: Safety Instructions

    Important Safeguards Safety Instructions • • • • • • • • • • • Unplug equipment before cleaning. Don't use liquid or spray detergent; use a moist cloth. Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with temperatures not exceeding 40º...

  • Page 7: Chapter 1 Introduction

    There are two types of the product: T1700 and T1900. These models are identical in almost every aspect except that T1700 comes with a 17" LCD monitor and T1900 comes with a 19" one.

  • Page 8: Structure Diagram

    Chapter 1: Introduction Structure Diagram 1. Carry handle to release the 2-pt lock 2. 2-point lock 3. LCD screen 4. LCD membrane 5. Adjustable rear mounting L-bracket 6. Micro switch for screen auto power off 7. Keyboard 8. Touchpad...

  • Page 9: Chapter 2 Installation

    Installation Chapter 2 In This Chapter Before Installation...3 Rack-Mounting the LCD KVM Console ...3 How to Install "One Man" Installation Slides ...6 Connecting to the KVM Switch via PS/2 Interface ...10 Connecting to the KVM Switch via USB Interface...11 Connecting to the Server via PS/2 Interface ...12 Connecting to the Server via USB Interface...12 Before Installation •...

  • Page 10: Installing The Rear L-Bracket

    Chapter 2: Installation 1. Installing the Rear L-bracket 2. Aligning the Rear L-brackets a. Install each rear L-bracket using two fasteners shown in the diagram. b. Leave the fasteners slightly loose. a. Measure the front and rear mounting depth of the rack. b.

  • Page 11: Fixing The Lcd Kvm Console Into The Rack

    Chapter 2: Installation 3. Fixing the LCD KVM Console into the Rack Fix the LCD KVM Console into the rack. Note: Hardware (screws and cage nuts) for fixing the mounting bracket into the rack is not provided.

  • Page 12: How To Install "One Man" Installation Slides

    Chapter 2: Installation How to Install "One Man" Installation Slides Component list Mounting bracket x 2 pcs Front mounting ear (left & right) x 2 pcs Support bracket x 4 pcs M6 cage nut x 6 pcs M6 washer x 8 pcs...

  • Page 13: Installing The Front Mounting Ear X 2 Pcs

    Component list M6*15mm screw x 8 pcs M3.2*4.5mm screw x 14 pcs Installing the Front Mounting Ear x 2 pcs 1. Disassemble the standard front mounting ears carefully. 2. Install the optional front mounting ears with M3.2*4.5 mm screw x 8 pcs.
  • Page 14 Chapter 2: Installation • Attach the mounting bracket to vertical mounting rails. • Adjust the rear mounting bracket to fit your rack. • Repeat the above steps for the other side. Caution: Leave the screws slightly loose (not release). • Attach support brackets to chassis with M3.2*4.5mm screw x 3 pcs.
  • Page 15 Chapter 2: Installation • Pick up the chassis. • Insert inner members of slides into the already mounted internal slide members in the rack. • Push the white-arrow button on each slide that is installed on the LCD keyboard drawer to unlock (Push at the same time).

  • Page 16: Connecting To The Kvm Switch Via Ps/2 Interface

    Chapter 2: Installation Connecting to the KVM Switch via PS/2 Interface This is an illustration of connecting the 3-in-1 KVM cable to the KVM switch via PS/2 Interface. 1. 3-in-1 KVM cable 2. KVM switch 3. Keyboard port 4. Mouse port 5.

  • Page 17: Connecting To The Kvm Switch Via Usb Interface

    Caution: The LCD KVM Console is hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable. Plugging and unplugging cables while servers and KVM switches are powered on may cause irreversible damage to the servers, KVM switches and LCD KVM Console.

  • Page 18: Connecting To The Server Via Ps/2 Interface

    Chapter 2: Installation Connecting to the Server via PS/2 Interface This is an illustration of connecting the 3-in-1 KVM cable to a server via PS/2 interface. 1. 3-in-1 KVM cable 2. Server 3. Keyboard port 4. Mouse port 5. VGA port Connecting to the Server via USB Interface...
  • Page 19 Chapter 2: Installation 1. 3-in-1 KVM cable 2. Server 3. USB port 4. VGA port...

  • Page 20: Chapter 3 Operation

    Operation Chapter 3 In This Chapter How to Use the LCD KVM Console...14 How to Use the Slides ...18 How to Use the LCD KVM Console 1. Gently pull the tab toward the front of the LCD. 2. Flip up the LCD to a suitable angle.

  • Page 21: Touchpad Buttons

    3. Operate the LCD KVM Console. For information on LCD membrane buttons and onscreen menu, see page 16) and Onscreen Menu Touchpad Buttons The buttons adjacent to the touchpad function the same as those on a three-button mouse. Number Function The button is similar to the left button on a mouse, which is used for item selection or program activation.

  • Page 22: Onscreen Display Operation

    Chapter 3: Operation Number Function Onscreen Display Operation 1. LCD membrane The button is similar to the middle button on a mouse, which is used to control the scrolling action. a. Press this button once, and a scrolling icon appears, indicating that you have entered the scrolling mode.

  • Page 23: Onscreen Menu

    Chapter 3: Operation Membrane button or LED Function Light off = Power off Blue = Power on Power on/off LCD Display the OSD menu Scroll through menu options and adjust the display control Exit the OSD screen. Shortcut key to auto-adjustment by pressing the button for 5 seconds or toggle analog, digital &...

  • Page 24: How To Use The Slides

    Chapter 3: Operation BRIGHTNESS / CONTRAST • • AUTO ADJUST • • PHASE/CLOCK • H/V POSITION • MISC • • • • Reset • How to Use the Slides 1. Locate a white-arrow release button on the outside of each slide. Brightness: Adjust background black level of the screen image.
  • Page 25 2. Push the white-arrow buttons together at both sides before pushing the LCD KVM Console into place. Avoid pushing the red button located on each slide. 3. Keep pushing the white-arrow buttons until the LCD KVM Console is placed into the rack. Chapter 3: Operation...

  • Page 26: Appendix A Standard Specifications

    640 x 480, 60 / 72 / 75Hz 800 x 600, 60 / 70 / 72 / 75Hz 1024 x 768, 60 / 70 / 72/ 75Hz 1152 x 864, 60 / 70 / 75Hz T1900 19" TFT 16.7 Mil. 1000:1...

  • Page 27: Dimension

    (W x D x H) 442 x 650 x 44 mm T1700 17.4 x 25.6 x 1.73 inch 442 x 650 x 44 mm T1900 17.4 x 25.6 x 1.73 inch T1900 Packing Dimension Net Weight (W x D x H)

  • Page 28: Appendix B Troubleshooting

    Troubleshooting Appendix B • How do I adjust the resolution? To change monitor resolution, choose Start > Control Panel > Display. Select the Setting tab to adjust the monitor resolution in Desktop Area. Available resolutions, including "640 x 480", "800 x 600", "1024 x 768", "1152 x 864", and "1280 x 1024", are determined by the display card in your computer.

  • Page 29: Index

    Rack-Mounting the LCD KVM Console • 3 Safety Instructions • vi Specifications • 20 Standard Specifications • 20 Structure Diagram • 2 T1700 • 1 T1900 • 1 Touchpad Buttons • 15 Troubleshooting • 22 What the Warranty Does Not Cover • v...
  • Page 30 U.S./Canada/Latin America Monday - Friday 8 a.m. - 6 p.m. ET Phone: 800-724-8090 or 732-764-8886 For CommandCenter NOC: Press 6, then Press 1 For CommandCenter Secure Gateway: Press 6, then Press 2 Fax: 732-764-8887 Email for CommandCenter NOC: tech-ccnoc@raritan.com Email for all other products: tech@raritan.com China Beijing Monday - Friday...
