User Manual
Raritan LED KVM Console
Thank you for your purchase of Raritan's LED KVM Console, which is one of the best-known LED-backlit LCD consoles
in the current market. Raritan's LED KVM Console solution is an integrated, 1U device that manages servers or KVM in
data centers, server rooms and other space critical environments - directly from the racks where they are installed.
Raritan provides two LED KVM Console models: T1700-LED and T1900-LED. Both are functionally identical except for
their monitor dimensions and supported video resolutions.
This Quick Setup Guide explains how to install and configure an LED KVM Console. For details on using this product,
access Online Help or User Guide on the
Package Content
The LED KVM Console comes with standard parts shown
below. Check and make sure they are included and in good
condition. If anything is missing or damaged, contact Raritan
or the local vendor immediately.
LED KVM Console
Rackmount brackets
* Mounting depth adjustable from 520 to 908 mm
KVM combo cable (VGA, USB, PS/2)
DVI cable
Quick Setup Guide
Warranty card
Power cord
Drawer key (to unlock the console)
QS Rule
LED KVM Console Quick Setup Guide
QSG-T1700LED_T1900LED-1A-v1.1-E 255-37-0001-00 RoHS
Support page
http://www.raritan.com/support/
(
Structure Diagram
1. Touchpad
2. Keyboard
3. Indicators for Num Lock, Caps Lock and Scroll Lock status
4. LCD display
5. OSD buttons and indicator lamp
6. Adjustable mounting brackets
QUICK SETUP GUIDE
).
