Congratulations on your purchase of the 16x16 ModularMX Matrix. Your complete satisfaction is very important to us.
The tvONE 16x16 ModularMX Matrix provides an all-in-one professional solution to route up to 16 DVI or DisplayPort sources to any 16 DVI outputs supporting
resolutions up to 1920 x 1200. The modular design of this 16x16 matrix provides the ultimate in fl exibility by allowing the combination of diff erent input and output cards
and the extension of inputs and outputs over CAT5-ELR or fi ber. The front-panel LCD displays the current routing status and each source is accessible to any display
by using the front-panel push buttons, the RS-232 interface, or through IP Control (with built-in web server, Telnet, and UDP). Hot-swappable dual redundant power
supplies allow these matrixes to be used for applications in demanding 24/7 applications where enhanced reliability, ease of servicing and zero down-time are required.
Page 1
Congratulations on your purchase of the 16x16 ModularMX Matrix. Your complete satisfaction is very important to us. The tvONE 16x16 ModularMX Matrix provides an all-in-one professional solution to route up to 16 DVI or DisplayPort sources to any 16 DVI outputs supporting resolutions up to 1920 x 1200.
For 24 / 7 support, see the back of the product for the support number Refer to the last page of this Quick-Start Guide for contact information. NOTE: For important operational details and warranty information, refer to the User Manual, which can be downloaded from the Support section of the tvONE Web site...
Two ELR-POL output cards, providing a total of 16 ELR-POL ports. Each • MOD-16416-DVI of these outputs are connected to a Receiver unit, using a CAT-5e cable, allowing you to extend the DVI signal up to 330 feet (100 meters). 16 DVI Two DVI input cards, providing a total of 16 DVI inputs.
Page 6
Quick Start Guide Pre-confi gured Options (continued) • MOD-16416-ELR • MOD-16416-DPDVI Two ELR-POL input cards, providing a total of 16 ELR-POL ports. Two DisplayPort input cards, providing a total of 16 DisplayPort inputs. Each of these inputs are connected to a Sender unit, using a CAT-5e cable, allowing you to extend the DVI signal from a source up to 330 feet (100 Two DVI output cards, providing a total of 16 DVI outputs.
Page 7
Quick Start Guide Pre-confi gured Options (continued) • MOD-16416-DPELR • MOD-16416-DVI1FO Two DisplayPort input cards, providing a total of 16 DisplayPort inputs. Two DVI input cards, providing a total of 16 DVI inputs. Two ELR-POL output cards, providing a total of 16 ELR-POL ports. Each Two Fiber Optic output cards, providing a total of 16 SC-type fi ber optic of these outputs are connected to a Receiver unit, using a CAT-5e cable, connectors.
Page 8
Quick Start Guide Pre-confi gured Options (continued) • MOD-16416-1FO • MOD-16416-DP1FO Two Fiber Optic input cards, providing a total of 16 SC-type fi ber optic Two DisplayPort input cards, providing a total of 16 DisplayPort inputs. connectors. Each of these fi ber optic ports are connected to a Sender unit, allowing you to extend the DVI signal from a source up to 6600 feet (2000 Two Fiber Optic output cards, providing a total of 16 SC-type fi ber optic meters) using 50μ...
Page 9
Quick Start Guide Connections MOD-16416-DVI MOD-16416-DVIELR Connect up to 16 DVI sources to the DVI inputs. Connect up to 16 DVI sources the DVI inputs. Connect up to 16 DVI displays to the DVI outputs using DVI cables. Connect a CAT-5e cable (or better), up to 330 feet (100 meters) from each ELR-POL port on the Output card to each of the included ELR-POL Receiver units, as shown below.
Page 10
Quick Start Guide MOD-16416-DVIELR (continued) MOD-16416-ELR Connect a DVI cable from the DVI Out port on the ELR-POL Receiver unit to Connect a CAT-5e cable (or better), up to 330 feet (100 meters) from each a DVI display. ELR-POL input to each of the included DVI ELR-POL Sender units, as shown below.
Page 11
Quick Start Guide MOD-16416-ELR (continued) Connect a DVI source to the DVI input of each DVI ELR-POL Sender unit. Connect both AC power cords from the matrix to available electrical outlets. Connecting both AC power cords will provide redundancy should one of the power supplies fail.
Page 12
Quick Start Guide MOD-16416-DPDVI MOD-16416-DPELR NOTE: This package is similar to the DVI package, except for the fact that all NOTE: This package is similar to the DVIELR package, except for the fact that all inputs will be DisplayPort instead of DVI. Refer to the connection instructions for inputs will be DisplayPort instead of DVI.
Page 13
Quick Start Guide MOD-16416-DVI1FO Connect the up to 16 DVI sources to the DVI inputs on the matrix. 50μ OM3e/OM4, OM3, and 62.5μ OM1 multimode fi ber optic cable can be used. However, the maximum extension distance is dependent upon the type of fi ber optic cable used: Connect a single strand of SC-terminated multimode fi ber optic cable from each SC connector on the Output Card to each Receiver unit.
Page 14
Quick Start Guide MOD-16416-DVI1FO (continued) MOD-16416-1FO Connect both AC power cords from the matrix to available electrical outlets. Using single strand SC-terminated multimode fi ber optic cables, connect up Connecting both AC power cords will provide power redundancy should to 16 DVI Fiber Optic Sender Units to the SC connectors on the input card, one of the power supplies fail.
Page 15
Quick Start Guide MOD-16416-1FO (continued) 50μ OM3e/OM4, OM3, and 62.5μ OM1 multimode fi ber optic cable can be Connect a DVI display to each Receiver unit. used. However, the maximum extension distance is dependent upon the DVI-1FO-R type of fi ber optic cable used: •...
Page 16
Quick Start Guide MOD-16416-DP1FO NOTE: This package is similar to the DVI1FO package, except for the fact that all inputs will be DisplayPort instead of DVI. Refer to the connection instructions for the DVI1FO version if needed. Connect the up to 16 DisplayPort sources to the DisplayPort inputs on the matrix.
Quick Start Guide Removing and Installing Cards Removing Cards Loosen the fastening screws on both sides of the card (or cover plate) to be removed. Each card / cover plate has two fastening screws. WARNING: Cards are sensitive to Electrostatic Discharge (ESD) which can damage the card.
Quick Start Guide Installing Cards Locate the metal track on either side of the expansion slot. Secure the card by hand-tightening the fastening screws. Do not overtighten the screws. To prevent damage to the screws, do not use pliers or other high-torque devices. Carefully position the card between the upper and lower rail on each track and slowly push the card forward.
