5.2

Client Side Node Parameters

Section Title
Nodes
Column Title Function
Node_Name Provide name for node.
Node_ID Station Address of Remote Server Node.
Protocol Specify protocol used.
Adapter Specify which adapter this protocol uses.
IP_address IP address of client PLC.
5
Address_Type Specify Register Mapping Model.
Modbus_TCP_
Select remote Internet Protocol Port.
IP_Port*
Set to Multiple if Remote Server Node only supports Write
Write_Fnc*
Multiple function code 15 & 16.
Set to MD_Length if write-thru operation should write all
registers as specified by MD_Length.
Write_Length* By default write-thru writes a single register.
If Write_Length also specified on Map Descriptor, Map
Descriptor's parameter will be used.
Example
// Client Side Nodes for new devices where 65536 registers are available in each memory area
Nodes
Node_Name , Node_ID
Modbus device 1 , 1
// Client Side Nodes for devices where only 9999 registers are available in each memory area
Nodes
Node_Name , Node_ID
Modbus device 3 , 3
5
Optional for Modicon 5 digit devices.
, Protocol , Adapter
, Modbus/TCP , N1
, Protocol
, Modbus/TCP
Page 8 of 23
Modbus TCP/IP Driver Manual
Legal Values
Up to 32 alphanumeric
characters
0 – 255
Modbus/TCP
N1
Valid IP address (for
example - 192.168.1.13)
ADU,PDU,
Modicon_5digit
1-65534, 502
Multiple, -
MD_Length, -, 1
, Address_Type , IP_Address
, ADU , 192.168.1.172
, Adapter , IP_Address
, N1 , 192.168.1.172
