Summary of Contents for PureLink VIP200H-RX
- Page 1 VIP-200 Video over IP Extender and Matrix System Many to Point Switching Configuration Quick Start Guide PureLink 535 East Crescent Avenue Ramsey, NJ 07446...
-
Page 2: Table Of Contents
PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 Contents What is in the box ............................3 Transmitter kit Receiver kit ......................... 3 Rack Mount Option Plates ..........................3 Overview ................................. 4 Auto IP Addressing (recommended) ......................4 Manual IP Addressing ..........................4 DHCP Addressing ............................ -
Page 3: What Is In The Box
PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 What is in the box Transmitter kit Receiver kit 1x transmitter (VIP200H/D/V-TX) 1x transmitter (VIP200H/DV-RX) 1x Power Adapter 1x Power Adapter 1x Infrared Receiver 1x Infrared Emitter Remote Control HDMI Transmitter... -
Page 4: Overview
PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 Overview The VIP200 series allows point to point, point to many, many to point, and many to many configurations. The VIP200 series allows easy configuration of many transmitters to one receiver. -
Page 5: Dhcp Addressing
PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 DHCP Addressing The VIP200 device IP addresses can be configured to accept IP addresses using DHCP. Using our simple software application to identify the devices, you can then access their built in web page interface to change the devices to DHCP IP mode. -
Page 6: One Transmitter To Multiple Receiver Setup (Point To Many Distribution)
PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 Many Transmitters to One Receiver Setup (Many to Point Distribution) Receiver Transmitter remote control Network Switch iCON VPX Software Example Application – Many to One Many to point connection via CAT5e or better cable (CAT6a cable recommended) VIP200 Transmitters and Receivers ship in Auto IP mode, which allows them to discover each other with no configuration required. -
Page 7: Kvm Operation
PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 KVM Operation The receiver has four USB ports, the first port operates at 1.1 speeds, and the remaining ports operate at 2.0 speeds. Please use ports 2,3 or 4 when using a mouse or keyboard via USB to ensure ultra-low latency. -
Page 8: Remote Control
PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 Remote Control Initial setup of remote control A remote being used for the first time, or after battery replacement, needs to be assigned an ID The universal ID that will control all receivers is 8. Press the ‘Power’ and ‘8’ button at the same time. -
Page 9: Mute/Unmute Image
PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 • Stop Link o “Menu”, “7”, “Enter” • Enable Channel Buttons on Receiver (one transmitter = one channel) o “Menu”,”26”,”Enter” • Disable Channel Buttons on Receiver (recommended setting) o “Menu”,”27”,”Enter”... -
Page 10: Troubleshooting - Point To Many
PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 Troubleshooting – Many to One Transmitter reports no source (via OSD on Receiver lower left corner) • Check source is active • Ensure input cable is plugged in to correct port on transmitter (input vs loop out) •... - Page 11 PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 a video signal is present, you can request display of the host (transmitter) and client (receiver) with the following remote control buttons: 2. Network Discovery This method is available only when the transmitter(s) and receiver(s) are connected together via a network switch, and a computer running the iCON VIP Device Manager discovery tool is utilized.
-
Page 12: Specifications
PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 Specifications Subject to change without notice... -
Page 13: Network Switch Requirements
PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 Network Switch Requirements While a Point to Point normally is configured with the transmitter and receiver directly connected to each other by CAT cable, it is possible to have point to point over a network switch. The requirements for a network switch are: •... - Page 14 PureLink VIP-200 Many to Point Distribution Quick Start Guide V1.0 The VIP lines of PureStream IP Video products can be found at the purelinkav.com website http://main.purelinkav.com/main/index.php?dispatch=products.view&product_id=223...
