CAUTION
Ensure that all power to the appliance is off at the electrical breaker or fuse
before beginning installation. Ensure gas is turned off at the shutoff valve before
beginning installation.
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO NOT
General Information
This remote control system can be used for the
Montigo R-Series and RP Series fireplaces.
The system can be operated manually from the
receiver using the slider switch.
Page 1
RXM5010 Touchscreen Remote
Installation and Operation Manual
This kit should be installed by a qualified person.
®
Check local codes and read all instructions prior to
installation.
C
US
ATTEMPT TO INSTALL OR OPERATE.
MODEL: RXM5010
ON/OFF Touchscreen Remote with 110v
receiver and battery for R-Series and
WARNING
Some materials used in the manufacturing process of this product can
expose you to Benzene which is known in the State of California to
cause cancer and birth defects or other reproductive harm. For more
information go to www.P65warnings.ca.gov
Before You Begin
Please read all instructions carefully
We strongly recomment that all electrical service
work be performed by a qualified electrical
contractor.
Check to ensure that all components required for
installation are included in your package.
RP-Series Fireplaces
XG0675 - 151207
