Bahco Torque Screwdrivers BE-6990-AH Specification

Torque screwdrivers with pre-settable torque values 0,5 – 15 nm, for 1/4" blades
Hide thumbs
1
2

Advertisement

Table of Contents

BE-6990-AH
Torque Screwdrivers
with pre-settable torque values
0,5 – 15 Nm, for
1/4" blades

Operation

Torque Screwdriver BE-6990-IP uses a built-in
slip free cam mechanism.
Smooth disengagement prevents overtightening.
Accurate and easy setting guaranteees the
accordance with the requirements of
DIN/ISO 6789 and EN 26789.
Accuracy ± 6 % with a lifetime up to at least
20,000 applications.
1/4" hexagon blade holder.

Material

3-component handle made of polyamide,
ESD Nitrile Rubber, shore hardness 70 degrees
and aluminium alloy with anodisied black finish.
Lockable
sliding T-handle

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Torque Screwdrivers BE-6990-AH and is the answer not in the manual?

Questions and answers

Related Manuals for Bahco Torque Screwdrivers BE-6990-AH

Summary of Contents for Bahco Torque Screwdrivers BE-6990-AH

  • Page 1 BE-6990-AH Torque Screwdrivers with pre-settable torque values 0,5 – 15 Nm, for 1/4" blades Operation Torque Screwdriver BE-6990-IP uses a built-in slip free cam mechanism. Smooth disengagement prevents overtightening. Accurate and easy setting guaranteees the accordance with the requirements of DIN/ISO 6789 and EN 26789.
  • Page 2 Adjustments can be made easily and accurately with the torque calibration rig as illustrated opposite. Accuracy: ± 6% Product code EAN code 731415+ BE-6990-AH 1848651 5 mm + Nm – Nm 0,5 – 15 1/4" 1/4" www.bahco.com – + ✔ 5 mm 32 x 150...
