- Page 1 HRB001 Server Installation Guide June 2017 Page 1 of 12...
-
Page 2: Table Of Contents
Assembling the Outer Rails ..................... 8 2.4.4 Installing the Outer Rails to the Rack ................8 2.4.5 Installing the HRB001 Server into a Rack ................ 9 2.4.6 Removing the HRB001 Server from a Rack ..............10 User Maintenance ......................... 11 Warranty and User Support ...................... -
Page 3: Introduction
This document is the server installation guide, advising how the HRB001 server should be installed and deployed. The server will have been delivered with pre-installed Deep-Secure software. - Page 4 Ethernet wiring made to the HRB001 server should be internal to the building containing the server, due to risk of lightning strikes. Only an appropriately rated and approved cord-set should be used with this equipment in accordance with the regulations of the country of use.
-
Page 5: Rack Installation
Basic electrical safety precautions should be followed to protect yourself from harm and the HRB001 server from damage. Be aware of the locations of the power on/off switch on the server as well as the room’s emergency power-off switch, disconnection switch or electrical outlet. -
Page 6: Rack Mounting Considerations
Use a regulating uninterruptible power supply (UPS) to protect the server from power surges, voltage spikes and to keep your system operating in case of a power failure. Allow the hot plug power supply modules to cool before touching them. Always keep the rack’s front door and all panels on the server closed to maintain proper cooling. -
Page 7: Rack Mounting Instructions
Rack Mounting Instructions This section provides information on installing the HRB001 server into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using. -
Page 8: Assembling The Outer Rails
Figure 2-3: Pre-installed inner rail 2.4.3 Assembling the Outer Rails The chassis rail (b.) comprises 2 parts, as shown in Figure 2-2. The part stamped Back should be placed down with the lettering uppermost and the front parted offered up with the word Front visible and engage the lugs. Figure 2-4: Assembled outer rail 2.4.4 Installing the Outer Rails to the Rack... -
Page 9: Installing The Hrb001 Server Into A Rack
Figure 2-5: Front of outer rail correctly installed 2.4.5 Installing the HRB001 Server into a Rack Confirm that the inner rails are attached to the server. Also, confirm that the outer rails are installed on the rack before proceeding to install the server into a rack. -
Page 10: Removing The Hrb001 Server From A Rack
Use the supplied rack bolts (a.) to securely attach the server to the front of the rack rail. 2.4.6 Removing the HRB001 Server from a Rack Before removing the server from the rack ensure that all cables have been removed. -
Page 11: User Maintenance
User Maintenance Maintenance tasks are limited to routine cleaning and inspection. The warranty will be invalidated if any attempt is made to open the unit. Check that all cables and connectors are undamaged and secure. If required, clean the external surfaces with a dry, lint-free cloth. Page 11 of 12... -
Page 12: Warranty And User Support
Warranty and User Support Warranty for the HRB001 server is provided in accordance with the Deep-Secure Limited, Hardware Supply Agreement, Version 1.0. For Warranty and Returns advice contact: support@deep-secure.com No unit should be returned without prior arrangement with your supplier.
