2018/06/02 13:16
Impedance - cabinet 1 Impedance - cabinet 2 Total impedance
16
16
16
16
8
8
8
8
4
4
4
4

5.7 Technical Data

Designation
Characteristics
Jack 6.35mm (1/4") unbalanced (TS, Tip/Sleeve)
Speaker Input
Maximum input voltage: 140 Volts AC (45 dBu)
Security load: 220 Ohms / 10 Watts
Reactive load, nominal impedance: 4 or 8 or 16 Ohms switchable
Maximum admissible power: 150W (assuming proper ventilation)
Loadbox
Maximum temporary admissible power : 200W (assuming proper ventilation)
(see
Cooled by temperature-controlled fan
2x Jack 6.35 mm (1/4") unbalanced (TS)
Minimum load: 4 Ohms
Maximum output power:
Speaker Outputs
• 25 W RMS@ 16 Ohms
• 50 W RMS@ 8 Ohms
• 70 W RMS@ 4 Ohms
Balanced XLR
Output Impedance: 600 Ohms
Ground/Lift switch
Loadbox Output
Attenuation (speaker input to balanced loadbox output): 24.5 dB \\Maximum
output level (balanced): 20.5 dBu
Noise: under -98 dBu from 20 Hz to 20 kHz
Frequency response @ -1dB: 5 Hz to 24 kHz
Jack 6.35mm (1/4") balanced (TRS, Tip/Ring/Sleeve)
Maximum input level: 36 dBu
REPLAY™ Input
Input impedance: 20 KOhms
Ground/Lift switch
Jack 6.35 mm (1/4") unbalanced (TS)
Impedance: 300 Ohms
Gain (In to Out): 0 to -inf dB, adjustable by potentiometer
REPLAY™ Output
Maximum output level: 19 dBu
Noise: under -98 dBu from 20 Hz to 20 KHz
Frequency response @ -1dB: 0 Hz to 18 kHz
Jack 6.35 mm (1/4") unbalanced (TS, Tip/Sleeve)
DI Input
Impedance : 1 MOhms
User's manuals - http://wiki.two-notes.com/
25/27
No cabinet
16
8
4
No cabinet
16
8
4
No cabinet
16
8
4
this article
if your amplifier is more powerful)
Result
16
OK
8
OK
5.3
OK
3,2
IMPOSSIBLE
8
OK
5.3
OK
4
OK
2.7
IMPOSSIBLE
4
OK
3.2
IMPOSSIBLE
2.7
IMPOSSIBLE
2
IMPOSSIBLE
Torpedo Reload User's Manual
