Summary of Contents for BH FITNESS G2338I
-
Page 2: Table Of Contents
Dear Customers, We want to thank you for having chosen an Elliptical trainer and wish you a lot of fun and success during training. Please note and follow the enclosed safety and assembly instructions carefully. If you have questions please do not hesitate to contact us. Table of Content as below: 1.) Safety Instruction---------3 2.) Exploded Drawing--------4... -
Page 3: Safety Instruction
SAFETY INSTRUCTION Thank you for purchasing our product. Even though we go to great efforts to ensure the quality of each product we produce, occasional errors and /or omissions do occur. In any event should you find this product to have either a defective or a missing part, please contact us for a replacement. This product has been designed for home use only. -
Page 4: Exploded Drawing
IMPORTANT HINTS: A) Parents should be aware of their responsibility with respect to their children natural play instinct. This can cause situations in which the product can be used for other purpose than intended. B) If children are allowed to use the product, the mental and physical condition and the temper of the children should be taken in consideration. -
Page 5: Parts List
PARTS LIST DESCRIPTION Q'TY NO. DESCRIPTION Q'TY 1 Console 43 Tension cable 2 Screw M5 x 10 44 Fly wheel 3 End cap 45 Chain adjuster set 4 Hand grip 46 Flange nut 5 Screw M2.5 x 33 47 Axle cap 6 Hand pulse wire 48 Drill screw M5 x 15 7LF Upper central shaft plastic cover - LF... -
Page 6: Assembly Instruction
DESCRIPTION Q'TY 92 Screwdriver 93 Multi hex tool 94 Adaptor 95 Washer Ø8 x Ø16 x 1.5t ASSEMBLY INSTRUCTION... - Page 11 Now, your machine is ready for use. Note: Before using the machine, make sure all the screws are fasten tightly.
-
Page 12: Computer Instruction
COMPUTER INSTRUCTION I. Display: 1. The field is an individual LCD displaying : TIME, RPM\SPEED, DISTANCE, WATT\CALORIES, PULSE, USER . II. Modes: POWER Mode: When powered on, the beeper beeps a long sound, and the full screen is display is 2 seconds, then it is into the Manual mode (As Fig-1,Fig -2) SLEEP Mode: When rpm signal or data is not input for 4 minutes, it will automatically enter Sleep... - Page 13 IV. Program operation instructions: Press ENTER button into Choose PROGRAM: By pressing the ▲ or ▼ button to adjust the profiles and it can be set the circle(select programs): MANUAL→PROGRAM→FITNESS→WATT→PERSONAL→H.R.C.→RANDOM If Press ENTER button to accept MANUAL By pressing the ▲ or ▼ button to adjust the LEVEL(1-24). Press ENTER button to accept LEVEL.
- Page 14 If Press ENTER button to accept RANDOM By pressing the ▲ or ▼ button to adjust the TIME value. Press ENTER button to accept TIME. By pressing the ▲ or ▼ button to adjust the DISTANCE value. Press ENTER button to accept DISTANCE. By pressing the ▲ or ▼ button to adjust the CALORIES value. V.
- Page 15 ● P7 ● P8 ● P9 ● P10 ● P11 ● P12 Program Profile for the H.R.C.(55%, 75%, 90%, Tag) Program ●HRC(55%) ●HRC(75%) ●HRC(90%) ●HRC(Tag) VI. Recovery Test: During the START or PAUSE stage, leave the hands holding on grips or leave the chest transmitter attached and then press PULSE RECOV.
- Page 16 Note: Fitness of a user is shown by Message. Figure State EXCELLENT VERY GOOD GOOD FAIR POOR VERY POOR VII. FITNESS Test: Entry into the FITNESS program, started testing and the test time is 8 minutes. The results as follows: Figure State VERY GOOD...
- Page 17 IX. Functions View: Item Windows Display Rang Default Stored MALE/ FEM Male 10 - 100 WEIGHT 20 - 330(Lb) 10 - 150(KG) HEIGHT 36 - 84(INCH) 90 – 210(CM) 0:00 - 99:59 0: 00 TIME DISTANCE 0.0 - 99.99 CALORIES 0 - 999 SPEED 0.0 - 99.9...
