iStarUSA BPX-35U3-SA User Manual

3.5” to 2.5” sata 6.0 gbps hdd/ssd hot-swap rack for internal sata and external usb 3.0 applications

Advertisement

Quick Links

BPX-35U3-SA 3.5" to 2.5" SATA 6.0 Gbps HDD/SSD Hot-Swap Rack
i StarUSA - Powered by iStarUSA Group
727 Phillips Drive City of Industry, CA 91748
Introduction:
The iStarUSA BPX-35U3-SA gives you the exibility to bring your storage with
you quickly and easily without having to deal with numerous cables. When at
the o ce or at home, just insert the enclosure into the rack and you will
instantly have a super-speed SATA connection to your drive. If you need to take
it with you, just eject the enclosure, grab the included USB 3.0 cable, and you'll
still have access to all of your data while on the road.
Features:
• Easily connect a 2.5" HDD/SSD to your computer using
this specially-designed rack.
• Internally: Use the rack's SATA interface to connect.
• Externally: Connect to other computers conveniently with USB3.0 or USB2.0
(USB 3.0 cable included).
• Designed to minimize dust intrusion: The drive door closes automatically
when ejecting a drive from the enclosure.
• Aluminum alloy body for strength and e cient heat dissipation.
• LED indicators for power & HDD activity.
• Fits in any standard 3.5" drive bay.
• Compatible with 7mm & 9.5mm 2.5" SATA I/II/III HDD and SSD.
for Internal SATA and External USB 3.0 Applications
United States of America
Tel: 1-626-303-8885
Toll-Free: 1-888-989-1189
Email: sales@istarusa.com

Specifications:

Hot Swap
Standard Drive Bays
Dimensions (W x H x D)
102.0 mm x 25.2 mm x 165 mm
Material
HDD Interface
Weight
Cable
Order Information:
Model Number:
Color:
BPX-35U3-SA
Black
Hardware Information: Front View
D2
D1
Eject Button: Press the button to eject the HDD enclosure.
D2
Hidden LED indicator:
Solid blue illumination for HDD power on.
Blinking blue illumination for HDD access.
*Note: LED indicator might not work with some SSDs.
BPX-35U3-SA
User Manual
2.5" Drive: 1
3.5" Drive: 1
Aluminium (main body)
SATA
0.2 kg
SATA Cable Included (1pcs)
Floppy to Molex Power Cable Included (1pcs)
USB 3.0 Micro-B to Standard-A Cable Included (1pcs)
UPC Code:
846813036160
D1
