Monessen Hearth Mojo22-R Log Placement Instructions

Log Placement Instructions

Models: Mojo22-R/Mojo27-R
BEFORE YOU BEGIN
Mojo logs are sold separately. Do not handle these logs
with your bare hands. Always wear gloves to prevent
skin irritation from refractory material. After handling
the logs, wash your hands gently with soap and water to
remove any traces of refractory material.
WARNING
• Gloves are recommended when handling logs to
prevent skin irritation from loose fibers. Logs
are fragile - handle with care.
• Use only rock wool provided with log set.
• DO NOT ADD ADDITIONAL ROCK WOOL.
PLACE ROCK WOOL
Before installing logs, place rockwool in dime size
pieces evenly over small burner ports starting in front
of the rear deflector shield towards the front. Avoid
placing rock wool over the slots on rear and right side
of burner and on large yellow flame ports on front of
burner.
Wash hands after placing rock wool. Itching may
occur.
Dime-Sized
Pieces of Rock
Wool
Figure 1 - Installing Rock Wool
FP2011
place rock wool
Monessen • Mojo Log Placement Instruction Manual • 4614-903 Rev. A • 6/18
WARNING
The positioning of the logs is critical to the safe and
clean operation of this heater. Sooting and other
problems may result if the logs are not properly
and firmly positioned in the appliance. Never add
additional logs or embellishments such as pine
cones, vermiculite or rock wool to the heater. Only
use 2G-RW rock wool supplied with the unit.
Failure to position the parts in accordance with
diagrams below or to use only parts specifically
approved for this heater may result in property
damage or personal injury.
NOTE — This unit is supplied with eight (8) ceramic fiber
logs. Do not handle these logs with your bare hands.
Always wear gloves to prevent skin irritation from
ceramic fibers. After handling the logs, wash your hands
gently with soap and water to remove any traces of fibers.
Figure 2 - Correct Rock Wool Placement
1
