MAGNUM
UNVENTED
VENT-FREE
FIREBOXES
INSTALLATION AND

OPERATING INSTRUCTIONS

MODELS:
MCUF36 and MCUF42
For use with a listed gas-fired
unvented decorative room heater
not to exceed 40,000 BTU/hr. Do
Not Build a Wood Fire.
Carefully review the instructions
supplied with the decorative type
unvented room heater for the mini-
mum fi replace size requirement.
DO NOT INSTALL AN APPLIANCE
IN THIS FIREBOX UNLESS THIS
FIREBOX MEETS THE MINIMUM
DIMENSIONS REQUIRED FOR
THE INSTALLATION.
If the information in this manual is not followed
exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
– Do not store or use gasoline or other fl ammable
– WHAT TO DO IF YOU SMELL GAS
– Installation and service must be performed by
READ AND SAVE THESE INSTRUCTIONS
WARNINGS
WARNINGS
WARNINGS
WARNINGS
WARNINGS
WARNINGS
WARNINGS
WARNINGS
vapors and liquids in the vicinity of this or any
other appliance.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fi re department.
a qualifi ed installer, service agency or the gas
supplier.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MCUF36 and is the answer not in the manual?

Questions and answers

Related Manuals for Monessen Hearth MCUF36

Summary of Contents for Monessen Hearth MCUF36

  • Page 1: Operating Instructions

    MAGNUM UNVENTED VENT-FREE FIREBOXES INSTALLATION AND OPERATING INSTRUCTIONS MODELS: MCUF36 and MCUF42 WARNINGS WARNINGS WARNINGS WARNINGS WARNINGS WARNINGS WARNINGS For use with a listed gas-fired WARNINGS unvented decorative room heater If the information in this manual is not followed not to exceed 40,000 BTU/hr. Do exactly, a fire or explosion may result causing Not Build a Wood Fire.
