- Page 1 TDB014 OBD PORT TESTER OPERATING MANUAL TDB014! PAGE 1 VERSION 1.0! 01/02/2018...
- Page 2 CONTENTS CONTENTS CONTENTS INTRODUCTION PAGE 3 GENERAL OPERATION PAGE 4 VEHICLE TESTING PAGE 5 to 6 SPECIFICATION PAGE 7 CONTACT INFORMATION PAGE 8 DECLARATION OF CONFORMITY PAGE 9 TDB014! PAGE 2 VERSION 1.0! 01/02/2018...
- Page 3 • Monitor battery voltage with display The TDB014 enables you to make sure that the OBD port wiring has not been tampered with, as many owners are disconnecting the wires, swapping wires around and even cutting the OBD port out.
-
Page 4: General Operation
(Pins 1, 3, 8, 9, 11, 12, and 13) - these should flash when your vehicle uses either one on the pins for any function. These depend on the make, model and year. Please see list of pins used on page 6. TDB014! PAGE 4 VERSION 1.0! - Page 5 VEHICLE TESTING CONNECT TDB014 TO DIAGNOSTIC PORT CHECK TO SEE VOLTAGE AND LED OPERATION. TDB014! PAGE 5 VERSION 1.0! 01/02/2018...
- Page 6 SPECIFICATION MAXIMUM INPUT VOLTAGE 18 VOLTS MINIMUM INPUT VOLTAGE 6 VOLTS CONTINUOUS CURRENT RATING 1 AMP TEMPERATURE RANGE 0 TO 50 DEGREES CELSIUS DIMENSIONS 85mm x 45mm x 25mm WEIGHT 60 grams TDB014! PAGE 6 VERSION 1.0! 01/02/2018...
- Page 7 CONTACT INFORMATION The Diagnostic Box Diagnostic Box House Unit 8, Fairfield Meadow Orchard Way Chillington Kingsbridge Devon TQ7 2LB United Kingdom Tel : +44 1548 580348 Fax : +44 1548 580348 Email : info@thediagnosticbox.com Web : www.thediagnosticbox.com Skype : diagnosticbox...
-
Page 8: Declaration Of Conformity
EN 55022:1998, A1: 2000 + A2: 2003 EN 55024:1998, A1: 2001 + A2: 2003 204/108/EEC Following the Provisions of EMC Directive: Product conforms to class A emission standards Signed : G CHAMBERS Signed on behalf of The Diagnostic Box TDB014! PAGE 8 VERSION 1.0! 01/02/2018...
