- Page 1 TDB001 REMOTE CONTROL TESTER OPERATING MANUAL TDB001! PAGE 1 VERSION 1.0! 01/01/2013...
-
Page 2: Table Of Contents
CONTENTS CONTENTS CONTENTS INTRODUCTION PAGE 2 GENERAL OPERATION PAGE 3 SPECIFICATION PAGE 4 CONTACT INFORMATION PAGE 5 DECLARATION OF CONFORMITY PAGE 6 TDB001! PAGE 2 VERSION 1.0! 01/01/2013... -
Page 3: Introduction
INTRODUCTION The TDB001 Remote Control Tester has been designed to offer a quick and accurate way to test radio frequency (RF) remote controls and also infra red (IR) remote controls. The TDB001 offers a simple check that the remote is sending a signal, but more important that the frequency it is sending is correct. - Page 4 LCD Display Infra Red (IR) receiver window Power Button RF Antenna Magnetic Panel Battery Compartment TDB001! PAGE 4 VERSION 1.0! 01/01/2013...
-
Page 5: General Operation
Insert the batteries, ensuring correct polarity. Replace the rear cover. SWITCHING THE UNIT ON Press the button on the front panel once to turn unit on. The tester will power up, displaying version information and self check info. TDB001! PAGE 5 VERSION 1.0! 01/01/2013... - Page 6 Switch the unit ON, and wait for the self check to finish so that a 0 is displayed. Point the Infra Red Remote control towards the top of the unit as shown. If there is a signal being sent the tester will display ‘Infra’. TDB001! PAGE 6 VERSION 1.0!
- Page 7 Below is a table of frequencies used, and the expected readings that you may receive using the TDB001 in terms of accuracy. Some of these are not used on current models, but have been used in the past on older models.
-
Page 8: Specification
84 mm (W) x 140 mm (H) x 29 mm (D) CURRENT CONSUMPTION 40 mA 3.5 Numerical Backlit LCD Display ACCURACY +- 5% FREQUENCY RANGE 100 Mhz to 1000 Mhz AUTO POWER OFF 30 Seconds TDB001! PAGE 8 VERSION 1.0! 01/01/2013... -
Page 9: Contact Information
CONTACT INFORMATION The Diagnostic Box 24 Helmers Way Chillington Kingsbridge Devon TQ7 2EZ United Kingdom Tel : +44 1548 580348 Fax : +44 1548 580348 Email : info@thediagnosticbox.com Web : www.thediagnosticbox.com Skype : diagnosticbox TDB001! PAGE 9 VERSION 1.0! 01/01/2013... -
Page 10: Declaration Of Conformity
EN 55024:1998, A1: 2001 + A2: 2003 Following the Provisions of EMC Directive: 89/336/EEC TDB001 December 2012 Product conforms to class A emission standards Signed : ________________________ Signed on behalf of The Diagnostic Box TDB001! PAGE 10 VERSION 1.0! 01/01/2013...
