- Page 1 Installation Manual SPA BROADWAY MAXI...
- Page 3 INDICE RECEIVING THE EQUIPMENT ..................PREPARING THE PLACE FOR THE INSTALLATION ..........POSITIONING THE SPA ..................... ELECTRICAL CONNECTIONS ..................4.1. Earth connection ......................... 4.2. Equipotential connection ..................... 4.3. Mains situation ........................4.4. Mains connection ........................ HYDRAULIC CONNECTION ..................... FILLING AND EMPTYING THE SPA ................
-
Page 4: General Specifications
It should be installed in accordance with INSTALLATION current regulations following all the applicable instructions. Broadway Maxi Spa can function indoors and outdoors. BREACH OF THIS CONDITION RENDERS THE It must be installed on a fi rm base to prevent it from PRODUCT WARRANTY NULL AND VOID. - Page 5 fi g.1-a DETAIL A approx Access to interior components for post-installation maintenance Contact points between the base of the SPA and the ground (version without wooden panels).
- Page 6 fi g.1-b 2204 5 5x ventilation holes Contact places Access to interior components for post-installation maintenance Contact surface between the base of the SPA and the ground (version with wooden panels). fi g.2 Access to interior components for post-installation pump 3 maintenance - 0,75m sewage connection...
-
Page 7: Positioning The Spa
3. POSITIONING THE SPA 4.3. MAIN SITUATION The mains supply cable of the spa must be connected to - For appropriate operating conditions, the spa must be a fi xed installation. A plug is not acceptable. positioned on a carefully leveled, fi rm base. The electrical installation must be compliant with current - The total weight of the bath with water and seven peoples legislation governing low voltage. -
Page 8: Hydraulic Connection
5. HYDRAULIC CONNECTION 7. VENTILATION For the connection, use PVC pipes and appropriate The possible high temperature of the water in the spa adhesive for this type of material. Do not use metal (approximately 39 C) leads to steam condensation. pipes. - Page 9 fi g.4 Broadway Maxi electrical diagram 20AT 20AT L/HI N PE L/LO N PE L/HI N PE L/LO N PE L1 L2 L3 N PE BOMBA 1 BOMBA 1 BOMBA 2 BOMBA 3 VOLTAJE DE ENTRADA...
- Page 10 fi g.5 Massage circuit with pump...
- Page 12 (available in Spain only) (available in Spain only) 20091116 8S0228000...
