Technics SL-1200GR Operating Instructions

Adjusting the turntable startup/brake speed

Startup speed
You can select from three options of the time for the
turntable to reach the constant speed after
[START-STOP] is pressed.
Press the H button to increase the torque (the power
required to rotate) and shorten the time to stabilize
rotation. (The factory setting is [3]: highest.)

The confirmation lamp blinks the
specified number of times according to
the current setting when you press the
H or L torque button.

To change the setting, press the H or L
torque button while the lamp is lit two
seconds.
(Lit two seconds)

After you press the torque button, the
confirmation lamp blinks the specified
number of times showing the new
setting, stays lit for two seconds and
then goes off.
Example) When the setting is [1].
→
( Blinks
one time)
English
Example)
When the setting is [3].
→
(Blinks three times)
→
→
( Lit two (Off/end)
seconds)
Direct Drive Turntable System
BRAKE button ([1] - [5])
S (Slow) .............. Reduce the brake speed(-1)
F (Fast) ................ Increase the brake speed(+1)
Confirmation lamp
Torque button ([1] - [3])
L (Low) ............... Reduce the torque(-1)
H (High) ............. Increase the torque
Press the center of the button lightly.
Brake speed
You can select from five options of the time for the
turntable to stop after [START-STOP] is pressed.
(You can change the brake power.)
(The factory setting is [5]: fastest.)

The confirmation lamp blinks the
specified number of times according to
the current setting when you press the F
or S brake button.

To change the setting, press the F or S
brake button while the lamp is lit two
seconds.
(Lit two seconds)

After you press the brake button, the
confirmation lamp blinks the specified
number of times showing the new
setting, stays lit for two seconds and
then goes off.
Example) When the setting is [3].
→
( Blinks
three times)
SL-1200GR
Model No.
(+1)
Example)
When the setting is [5].
→
(Blinks five times)
→
→
( Lit two (Off/end)
seconds)
