KidKraft Slatted Toddler Bed Assembly Instructions

© 2011 KidKraft, LP
Please retain this information for future reference
HARDWARE: PARTS LIST:
A. Cross Dowel
Bolt x 18 pcs
(2 1/8 in / 54 mm)
B. Cross Dowel Nut
x 16 pcs
1
C. Wood Screw
x 8 pcs
2
(13/16 in / 20 mm)
D. Cross Dowel
Bolt x 4 pcs
4
(1 3/8 in / 35 mm)
E. Nylon Lock Nut 5
x 6 pcs
Step 2
F. Screw x 8 pcs
(1/2 in / 12 mm)
G. Metal Plate x 2 pcs
Wrench x 1 pc
Allen Wrench x 1 pc
5
The following tools
(not included) are
required for
assembly :
Phillips screwdriver
Flathead screwdriver
WARNING:
ADULT ASSEMBLY REQUIRED.
Product includes small parts with potentially hazardous sharp
points and sharp edges in the unassembled state. Keep
unassembled parts away from children.
WARNING:
CHOKING HAZARD. Small parts and sharp points, not
suitable for children under 3 years.
Slatted Toddler Bed
Assembly Instructions
The mattress intended for use on the bed shall be a full-size crib mattress having minimum
dimensions of 51 5⁄8 in. (1310 mm) in length, and 27 1⁄4 in. (690 mm) in width and 4 in. (100 mm) in thickness.
DO NOT USE FOR INFANTS. The toddler bed is intended for a child over 15 months old and less than 50 lbs. (22.7kg).
Before assembly, inspect toddler bed for damaged hardware, loose joints, missing pieces or sharp edges.
DO NOT use bed if any parts are missing or damaged. Do not substitute parts.
3
6
Step 3
A
A
A
6
8
B
A
B
B
B
A
4
WARNING:
USE AND MAINTENANCE:
-Use on level surfaces only
ENTRAPMENT/STRANGULATION HAZARD
-Please check assembly at regular intervals, and
Infants have died in toddler beds from entrapment and
frequently tighten hardware if necessary. If
strangulation. Failure to follow these warnings and the
maintenance is not carried out, the product could
assembly instructions could result in serious injury or death.
cease to function properly.
9
x 2
11
8
x 4
10
7
x 2
B
7
B
8
A
86925A, 86926A, 86927
To order replacement parts, please visit www.kidkraft.com
Step 1
B
B
B
B
B
1
B
2
Step 4
D
D
E
E
E
E
DO NOT place bed near windows where cords
from blinds or drapes may strangle a child.
DO NOT place items with a string, cord, or ribbon around
a child's neck, such as hood strings or pacifier cords.
DO NOT suspend strings over a toddler bed for any reason.
Item #86922B, 86923A
A
A
A
3
A
A
A
D
D
Customer Service
1-800-933-0771
www.kidkraft.com
1
