3.7 Endura AZ20 Probe Flanges – All Probe Lengths
Note. These flanges are not pressure rated.
Dimensions in mm (in).
Flange Type
ANSI 2 in 150
ANSI 2.5 in 150
ANSI 3 in 150
DIN 65 PN16
JIS 65 5K
JIS 80 5K
Table 3.1 4-Hole Probe Flange Types and Dimensions
Flange Type
ABB Standard
(0.5 m [1.64 ft.]
probes only)
ABB Standard
Table 3.2 6-Hole Probe Flange Types and Dimensions
Flange Type
ANSI 4 in 150
DIN 80 PN16
DIN 100 PN16
JIS 100 5K
Table 3.3 8-Hole Probe Flange Types and Dimensions
12
A B C
(Ø)
152.4 12 19
(6.00) (0.47) (0.75)
177.8 12 19
(7.00) (0.47) (0.75)
190.5 12 19
(7.50) (0.47) (0.75)
185 12 18
(7.28) (0.47) (0.70)
155 12 15
(6.10) (0.47) (0.59)
180 12 19
(7.08) (0.47) (0.75)
A B C
(Ø)
101 7.3
6 (0.24)
(3.97) (0.29)
165 12 12.5
(6.50) (0.47) (0.50)
A B C
(Ø)
228.6 12 19
(9.0) (0.47) (0.75)
200 12 18
(7.87) (0.47) (0.70)
220 12 18
(8.66) (0.47) (0.70)
200 12 19
(7.87) (0.47) (0.75)
D
(PCD)
120.6
(4.75)
139.7
(5.50)
152.4
(6.00)
145
(5.70)
130
C
(5.12)
D
145
(5.71)
D
(PCD)
80
(3.15)
140
(5.51)
D
C
D
(PCD)
190.5
(7.50)
160
(6.30)
180
(7.08)
C
165
D
(6.50)
3 Mechanical Installation
4-Hole Flanges
A
B
6-Hole Flanges
A
B
8-Hole Flanges
A
B
IM/AZ20P–EN Rev. G
