USER GUIDE

Headphones
Kygo A6-500

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A6-500 and is the answer not in the manual?

Questions and answers

Related Manuals for Kygo A6-500

Summary of Contents for Kygo A6-500

  • Page 1: User Guide

    USER GUIDE Headphones Kygo A6-500...
  • Page 3 - the drive to keep on improving, perfecting every little step of the process. This philosophy is now passed on to Kygo Life. It is built upon Scandinavian design with sophisticated items that have enough backbone to become classics. I hope you will enjoy them for years to come.

  • Page 4: Getting Started

    ENGLISH Getting started Congratulations on purchasing your new KYGO A6-500 Bluetooth stereo headphones. Before using them, please read through this manual carefully to learn how to cooperate the Bluetooth headphones with your mobile phone or other devices.
  • Page 5 Do not dismantle, repair or modify this product to prevent fire, electric shocks or other product damage, which are not covered under warranty. Do not use any solvents or volatile liquids to clean the Kygo A6-500 headphones. Do not use your Kygo A6/500 headphones in hazardous situations.
  • Page 6 ENGLISH Features Bluetooth 4.1 + EDR 3.5mm music line-in function Connect up to 2 phones or devices The headphone battery power status is displayed on iOS device’s screen Qualcomm® aptX™ and AAC® audio technology Supports NFC...
  • Page 7 ENGLISH Basic buttons operation LED indicator Volume up / Next Multifunction Button (MFB): Turn on / Pairing / Play / Pause / Turn off / Answer / End / Reject Call Volume down / Previous 3.5mm Audio Jack Micro USB Slot Microphone...

  • Page 8: General Function

    ENGLISH General Function Operation LED status Power on Blue LED flashes twice Power off Red LED flashes twice Pairing Blue LED and Red LED flash alternately Standby Blue LED flashes 3 times in 5 seconds Incoming call Blue LED flashes continuously Low battery Red LED flashes twice every 2 seconds Red LED stays lit during charging...
  • Page 9 ENGLISH Basic Buttons Operation Power on: Press the multi-functional button for 2 seconds. When the blue LED flashes twice, headphones are turned on. Power off: Press the multi-functional button for 3 seconds. When the red LED flashes twice and then stops, headphones are turned off. Pairing: Press the multi-functional button for 5 seconds, the blue LED and the red LED flash alternately.
  • Page 10 ENGLISH Previous song: Press and hold the “-“ button. Next song: Press and hold the“+“ button. Answer Call: Short press the MFB to answer incoming calls. End call: Short press the MFB to end calls. Reject call: Long press the MFB to reject calls. Battery Capacity status: When headphones are connected to iOS devices, the headphone battery power status is displayed on the upper right corner of the screen.
  • Page 11 ENGLISH 3.5mm music line-in with mic function:：Connect audio line in cable to 3.5mm audio jack for wired music. When plugged in, headphones will power off. (Phone call function can still be used in this mode).
  • Page 12 ENGLISH 3.5mm Audio Cable...
  • Page 13 Activate the Bluetooth function on your phone or device and search for the headphones. From the list of available devices on your mobile phone, select the KYGO A6-500 headphones and tap to connect. Follow the instructions to enter “0000” as a PIN code if prompted on your mobile phone screen.
  • Page 14 Turn on your phone and ensure its NFC functions are activated. Turn on KYGO A6-500. Place your phone close to the right side of the KYGO A6-500. When your phone prompts to confirm the connection, then press YES/OK to finish pairing.
  • Page 15 Pair with the phone “A” successfully, then turn off the headphones. Follow the same procedure with the phone “B”. Then turn off the headphones again. Turn on the headphones. The headphones will automatically connect to phone “B”. Then check “found devices” on phone “A” and connect to Kygo A6-500.
  • Page 16 ENGLISH Sound quality with Qualcomm® aptX™ and AAC® Sound quality with AAC® Sound quality with Qualcomm® aptX™ Thanks to Qualcomm® aptX™ codec, the headphones can connect wirelessly to any aptX enabled devices. Doing so vastly improves the quality of Bluetooth streaming and delivers CD-quality sound. Qualcomm aptX is a product of Qualcomm Technologies International, Ltd.

  • Page 17: Kit Contents

    ENGLISH Kit Contents 1 x Stereo Bluetooth headphones KYGO A6-500 1 x Charging micro USB cable 1 x User manual 1 x 3.5mm audio wire...

  • Page 18: Troubleshooting

    ENGLISH Trouble Shooting If you have any problems with your Kygo A6-500 headphones or questions about the functions, please contact us on info@kygolife. com and we’ll be glad to assist you. Warning You must choose a qualified charger from a regular manufacturer to charge the headphone.

  • Page 20: Specifications

    ENGLISH Specifications Bluetooth version: Talk time: Stand-by time: 200h Music play time: Wireless range: Bluetooth profiles: A2DP/AVRCP/HSP/HFP Audio codec: AAC/AptX/AptX-LL Impedance: 32Ω Sound pressure level: 119±3dB Frequency Response: 20Hz---22 KHz Weight: 135g Dimension: 160 x 190 x 70mm...
