Redback A 4920 Operating Manual

www.altronics.com.au
Operating Manual
A 4920
Pre Amplifier Balanced Mic/Line Wallplate

OVERVIEW

This remote mic/line pre-amp wallplate accepts either a microphone or line input for conversion to a balanced high level
signal. The 3V output signal is carried via Cat5e cable, suitable for distribution up to 500m without interference. Mic input
is via a balanced XLR whilst the line input is via 2 x RCA sockets or 3.5mm jack. The Cat5e output cable terminates to an
interface module enabling a balanced mic/line, or unbalanced line signal to be fed into the amplifier. Power is supplied via
the included 24V Plugpack which is connected to the interface box. Power for the wallplate is provided through the Cat5e
cable connection.

FEATURES

• Balanced 3 pin XLR mic input
• Dual RCA or 3.5mm line input (Note : audio is internally mixed to become mono signal)
• Up to 500m transmission range
• Uses economical Cat5e cable for connection between wall plate and interface box
• Balanced mic/line or unbalanced line output
• Level control
• Wallplate powered via Cat5e cable from interface box
• 24V DC plugpack supplied
Distributed by Altronic Distributors Pty. Ltd.
Phone: 1300 780 999 Fax: 1300 790 999 Internet: www.altronics.com.au
User manual revision number: 1.0 22/09/2016
Redback® Proudly Made In Australia
