Quick guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on

PRODUCT DESCRIPTION

FIRST TIME USE
Wait at least two hours, after the installation, before connecting
the appliance to the power supply. Connect the appliance to the
power supply it starts the operation automatically. The ideal storage
temperatures for the food are preset in the factory.

CONTROL PANEL

6
SENSE FRESH CONTROL
TH
The appliance is automatically able to quickly reach the optimal
internal preservation temperature. The 6
enables to control also the humidity of the appliance. In order for it to
function correctly, the fan must also be turned on. It is possible to turn
the function on/off (see Fan description).
FAN*
The Fan improves temperature distribution inside the product,
allowing better preservation of stored food and reduction of excess
humidity. By default, the fan is switched on. You can turn the fan on/
off by pressing for 3 seconds Stand by
buttons. The lit 6
Sense Fresh Control symbol indicates that the fan
th
is on and therefore the 6
Sense Fresh Control function is on. If the
th
ambient temperature exceeds 27°C, or if drops of water are present
on the glass shelves, it is essential that the fan is on to ensure the
proper preservation of the food. Deactivation of the fan allows energy
consumption to be optimised.
Note: the fan restarts automatically after a power cut or after turning off
the appliance. Do not obstruct the air intake area with food items.
ANTIBACTERIAL FILTER*
Remove it from the box placed in the Fruit and vegetable drawer and
insert into the cover of fan. The replacement procedure is included in
the filter box.
ON/STAND-BY
Press the button for 3 seconds to turn the appliance off (the
control panel and the light will remain turned off). Press the button
again briefly to reactivate the appliance.
Note: This does not disconnect the appliance from the power supply.
* Available only on certain models
www . whirlpool . eu/ register
1.
2.
8.
7.
6.
5.
Sense Fresh Control function
th
and Fast Cooling
Before using the appliance carefully read the Safety
Instruction.
After turning the appliance on, you must wait for 4-6 hours for the
correct storage temperature to be reached for a normally filled
appliance. Position the antibacterial anti-odour filter in the fan as
demonstrated in the filter packaging (if available). If the audible signal
sounds, it means that the temperture alarm has intervened: press the
button to switch off the acoustic alarms.
3.
4.
FREEZER AND REFRIGERATOR
COMPARTMENT TEMPERATURE
It is possible to set a different temperature of the appliance by pressing
the "Temp." button.
LEDs lit
Low
FAST COOL
Press the button
refrigerator compartment or 6 hours before putting large quantities
of food to freeze in the freezer compartment. When the function is
turned on the icon lights up. The function turns off automatically after
36 hours, or manually by pressing the button again for 3 seconds.
Note: Avoid a direct contact between the fresh food and the food that is
already frozen.
TURNING OFF THE SOUND ALARM
To turn off the sound alarm, briefly press the
1.
Freezer and refrigerator compartment
temperature indicator
2.
Fast cool
3.
6
Sense Fresh Control and Fan indicator
th
4.
On/stand-by
5.
Alarm indicator
6.
Turning off the sound alarm
7.
Black out alarm indicator
8.
Temperature button
Set temperature
High (less cold)
Medium-high
Medium
Medium-low
Low (colder)
High
for 3 seconds to quickly cool the
EN
button.
