WorkFit-C, Single LCD Mount, LD
User's Guide
Includes
Constant Force™
Technology
1 of 14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ergotron 24-215-085
Summary of Contents for Ergotron 24-215-085
- Page 1 User's Guide WorkFit-C, Single LCD Mount, LD For the latest User Installation Guide please visit: www.ergotron.com User's Guide - English Includes Guía del usuario - Español Constant Force™ Manuel de l’utilisateur - Français Gebruikersgids - Deutsch Technology Benutzerhandbuch - Nederlands Guida per l’utente - Italiano...
-
Page 2: Hazard Symbols
Hazard Symbols Symbol Signal Word Level of Hazard Review A NOTE indicates important information that helps you NOTE make better use of this product. These symbols alert users of a safety condi- tion that demands attention. All users should A CAUTION indicates either potential damage to CAUTION be able to recognize and understand the hardware or loss of data and tells you how to avoid the... - Page 3 6 - 16 lbs (2.7-7.3 kg) < 5 lbs (2.25 kg) < 2 lbs (0.9 kg) < 1.5 lbs (0.68 kg) Weight Capacity: 40 lbs. (18 kg) Capacidad de soporte de peso: 40 lbs. (18 kg) Capacité de poids: 40 lbs. (18 kg) Tragkraft: 40 lbs.
- Page 4 M3 x 6mm M4 x 10mm M5 x 8mm M6 x 16mm M4 x 10mm M6 x 22mm M5 x 8mm 5-sided Security Wrench Llave de seguridad pentagonal Clef Allen de sécurité Fünfkant-Inbusschlüssel 5-kantige veiligheidssleutel Chiave pentagonale di sicurezza 5角固定用レンチ M5 x 22mm 5角安全扳手...
- Page 5 M6 x 16mm M6 x 22mm 888-24-143-W-02 rev.G • 03/15 5 of 14...
- Page 6 M3 x 6mm 0° M4 x 10mm M4 x 10mm M5 x 8mm Release Brake to move riser. Suelte el freno para mover el elevador. Relâcher le frein pour déplacer la colonne montante. Lösen Sie die Bremse, um eine Höhenverstellung vorzunehmen. Zet de rem los om de staander te verplaatsen.
- Page 7 2.5mm 5-sided wrench llave pentagonal Clef Allen Inbusschlüssel 5-kantige sleutel Chiave a 5 lati 5 角レンチ 5角扳手 5면 렌치 NOTE: Center on bottom NOTA: Centre por la parte inferior REMARQUE : centrer la partie inférieure HINWEIS: Richten Sie die Geräte mittig aus. OPMERKING: Centreren op onderkant NOTA.
- Page 8 2.5mm CAUTION:Do Not over tighten fasteners. Over-tightening may cause damage to fasteners. 5-sided wrench llave pentagonal Clef Allen Inbusschlüssel 5-kantige sleutel Chiave a 5 lati 5 角レンチ 5角扳手 5면 렌치 888-24-143-W-02 rev.G • 03/15 8 of 14...
- Page 9 5-sided wrench llave pentagonal Clef Allen Inbusschlüssel 5-kantige sleutel Chiave a 5 lati 5 角レンチ M5 x 8mm 5角扳手 5면 렌치 M5 x 8mm 5-sided wrench llave pentagonal Clef Allen Inbusschlüssel 5-kantige sleutel Chiave a 5 lati 5 角レンチ 5角扳手 5면...
- Page 10 M5 x 22mm 5-sided wrench llave pentagonal Clef Allen Inbusschlüssel 5-kantige sleutel Chiave a 5 lati 5 角レンチ 5角扳手 5면 렌치 888-24-143-W-02 rev.G • 03/15 10 of 14...
- Page 11 NOTE: Leave enough slack in cable to allow full range of motion. Caution: To avoid the potential to pinch cables it is important to follow the cable routing instructions in this manual. Failure to follow these instructions may result in equipment damage or personal injury.
- Page 12 Adjustment Step Important! You will need to adjust this product after installation is complete. Make sure all your equipment is properly installed on the product before attempting adjustments. This product should move smoothly and easily through the full range of motion and stay where you set it. If movements are too easy or difficult or if product does not stay in desired positions, follow the adjustment instructions to create smooth and easy movements.
- Page 13 Increase Lift Strength If the mounted weight is too heavy or this product does not stay up when raised, then you'll need to increase Lift Strength: Decrease Lift Strength If the mounted weight is too light or this product does not stay down when lowered, then you'll need to decrease Lift Strength: Increase Friction...
- Page 14 Blink - Blink often to avoid dry eyes. Break • 2 to 3 minutes every 20 minutes • 15 to 20 minutes every 2 hours. For local customer care phone numbers visit: http://contact.ergotron.com © 2015 Ergotron, Inc. 888-24-143-W-02 rev.G • 03/15...
