Summary of Contents for Patio Glow ARX13200
- Page 4 ASSEMBLY INSTRUCTIONS CSA Model WT17YP4 ARX13200 Installer: Leave these instructions with consumer. Consumer: Keep these instructions for future reference WARNING: DANGER If you smell gas: Improper installation, adjustment alteration, 1. Shut off gas to the appliance. service or maintenance can cause injury or 2.
-
Page 5: Table Of Contents
TABLE OF CONTENTS Important Safety Information ..............3 Important Information about Propane............4 Specification ..................4 Parts Identification List ................5 Installation ..................6-7 Natural Gas Conversion ..............8-9 Maintenance ..................9 Batteries ....................10 Lighting Instructions ..............10-11 Troubleshooting Guide ................11 Warranty ....................12 ... -
Page 6: Important Safety Information
IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54; International Fuel Gas Code. ; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, B149.2, as applicable. The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5kPa). -
Page 7: Important Information About Propane
IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS A LP-gas cylinder for use with this appliance must have a capacity of 20 lbs / 9kg. and must be equipped with a Type 1 connector and an OPD (overfill protection device). Figure 1 The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specification for LP-gas cylinders of the U.S. -
Page 8: Parts Identification List
PARTS IDENTIFICATION LIST PART DESCRIPTION PART# CONTROL PANEL FP2187 LP REGULATOR HOSE FP1916 LP TANK RETAINING KNOB FP0585 ADJUSTABLE FOOT CAPS FC0553 PROPANE ORIFICE FP2205 NATURAL GAS ORIFICE FP2206 FIRE ICE FP2006 AIR SHUTTER FP1922 1/4” X20 MM BOLT HW0036 1/4”... -
Page 9: Installation
BURNER COVER FP2221 INSTALLATION 1. Carefully unpack all items from the box. Place the base in the final position. There must be a minimum of 24 in / 60.96 cm of clearance from the side of the table top to any combustible walls. - Page 10 4. Pour the lava rocks or fire ice into the burner pan completely covering the burner. The weight of lava rocks is (3.6kg plus and minus 10%); the weight of the fire ice is (8kg plus and minus 10%). Remove any lava rocks or fire ice on top of the ignition well. See Figure 4. Figure 4 5.
-
Page 11: Natural Gas Conversion
NATURAL GAS CONVERSION Natural gas conversion must be performed only by your natural gas provider or service company. 1. SHUT OFF THE GAS SUPPLY TO THE UNIT AND ANY NEARBY ELECTRICAL SOURCE OR APPLICANCES 2. Below the burner, carefully disconnect flex connector attached to the orifice holder (see step1). -
Page 12: Maintenance
9. Restore your gas supply and check ALL of the connections for leaks using a solution of soapy water. If a leak is discovered and any bubbles are seen, close the main gas valve and re-tighten ALL the connections. NEVER USE A FLAME TO CHECK FOR GAS LEAKS! Step5 10. -
Page 13: Batteries
BATTERIES Make sure the control knob is in the "OFF" position. Unscrew the push button cap on the ignition module located on the control panel to access the battery compartment. The ignition module requires one Alkaline AAA size battery (1.5V). The negative (-) end goes in first. -
Page 14: Troubleshooting Guide
should pop back out and then the fire remain lit. Note: If the fire does not light, turn the knob to the “OFF” position and wait five (5) minutes before trying again. 3. To turn down the flame, push the control knob in slightly and turn to Medium (medium flame), or Low (small flame). -
Page 15: Warranty
ONE-YEAR LIMITED WARRANTY What is Covered Under This Warranty? The item you have purchased is warranted against defects in material and workmanship for the following parts from the date of purchase for the period of warranty as outlined below, but only when the unit is installed and operated in accordance with the instructions in this Owner’s Manual and in compliance with local building and fire codes: Limited 1 Year...
