MX-U81 Hardware Guide
for Processor and Cameras
Revision Date: October 26, 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX-U81 and is the answer not in the manual?

Questions and answers

Related Manuals for Datalogic MX-U81

Summary of Contents for Datalogic MX-U81

  • Page 1 MX-U81 Hardware Guide for Processor and Cameras Revision Date: October 26, 2017...
  • Page 2 Datalogic S.r.l. reserves the right to revise this publication from time to time and to make changes in the content hereof without obligation to notify any person of such revision or changes.
  • Page 3 •Repair Program for On-Line Return Material Authorizations (RMAs) plus Repair Center contact information; •Service Program containing details about Maintenance Agreements; •Technical Support through email or phone.

  • Page 5: Table Of Contents

    Power Supply Connection.................. 2-5 Grounding Concepts ................... 2-6 USB Hardware Key .................... 2-7 CFast Card......................2-8 Battery........................ 2-9 Chapter 3: MX-U81 Cameras Introduction ......................3-1 Safety Precautions ..................... 3-1 U1xx Camera Dimensions ................. 3-3 Mounting the Camera..................3-3 Connecting the Camera ..................3-5 U1xx Camera Connection................
  • Page 6 Table of Contents MX-U81 Hardware Guide Ethernet....................... 5-1 Input/Output ....................5-1 Power Supply ....................5-1 Serial Port ....................5-2 Monitor/Panel ....................5-2 Display Port....................5-2 USB Processor to Camera................5-2 Camera Cable ....................5-3 U1xx ......................5-3 TOC-2 Datalogic S.r.l.

  • Page 7: Chapter 1: When Your System Arrives

    System Factory Setup Before we shipped your MX-U81 vision system, we ran the installation and setup program and specified a default soft- ware and hardware configuration. See page 1-4 for more information about setting up the hardware. Refer to the Impact Reference Guide for software configuration information.

  • Page 8: Hardware Components

    Hardware Components MX-U81 Hardware Guide Hardware Components The major hardware components of the system are the MX-U81 Processor, camera, and cables. • MX-U81-4-P-1 4-camera capable, PNP outputs: 959918109 • MX-U81-4-N-1 4-camera capable, NPN outputs: 959918110 • For details about MX-U81 cables, see “Processor Cables” on page 5-1.

  • Page 9: Turning Off The System

    (see “Front Panel Connections” on page 1-7). Processor Specifications This section lists the general operating specifications for the MX-U81. Only Datalogic USB cameras will operate with MX-U81 Processor. GigE cameras cannot be used. Each of the MX-U81 cameras has different operating specifications.

  • Page 10: Setting Up The System

    60529) Weight 4.52 lb. (2.05 kg) Minimum Impact Software 11.5.0 Version Required MX-U81: Intel® Core i7 2.3 GHz – quad core System Memory 8 GB DDR3 RAM Storage 128 GB SATA SSD (MLC) Graphics Intel® HD 3000 (1920x1200 resolution) - DVI...
  • Page 11 NOTE: Do not leave the camera imager uncovered. When you remove the lens cap, you must replace it with a lens. 6. Connect the camera to a Processor USB 3.0 camera port using a Datalogic USB 3.0 cable. See “Top Panel Connec- tions”...

  • Page 12: Top Panel Connections

    Top Panel Connections MX-U81 Hardware Guide Top Panel Connections This illustration shows the connections on the Processor’s top panel. Symbol Function USB 3.0 (x 4) ETH2 - Ethernet 2 (See “Status Lights” on page 1-9) ETH1 - Ethernet 1 (See “Status Lights” on page 1-9) RS232 Serial Port (COM 1) - See “Serial Port”...

  • Page 13: Front Panel Connections

    MX-U81 Hardware Guide Front Panel Connections Front Panel Connections This illustration shows the connections on the Processor’s front panel. Symbol Function Status Lights (see “Status Lights” on page 1-9) Power Button: Press and release to turn on the unit. If the unit is on, press and release to shut down the OS and switch off the unit (see “Turn-...

  • Page 14: Rear View

    Rear View MX-U81 Hardware Guide Rear View This illustration shows the Processor’s rear panel. Datalogic S.r.l.

  • Page 15: Status Lights

    MX-U81 Hardware Guide Status Lights Status Lights This illustration shows the status lights on the front of the Processor. Symbol Name When lit indicates: Power Power is On Solid-state hard drive or Cfast access is active Link On: An active Smart Display Link connection is estab-...

  • Page 16: Preventive Maintenance

    This section contains tips to keep your system trouble-free and operating smoothly. • Insure at least 1.5 inches (38.1 mm) of clearance on the sides and top of the MX-U81 Processor. • Periodically check mounting bolts for tightness and wear. The MX-U81 Processor should be mounted securely in a vibration-free location.

  • Page 17: Chapter 2: Basic Hardware Components

    C H A P T E R Basic Hardware Components Processor Views and Dimensions This section shows specifications for the Processor, including various views and dimensions. Top View Rear View Front View UNITS: mm Datalogic S.r.l.
  • Page 18 Processor Views and Dimensions MX-U81 Hardware Guide Side View UNITS: mm Air Inlet Filter Inside Datalogic S.r.l.

  • Page 19: Processor Installation

    MX-U81 Processors. An optional power supply is available for MX-U81 Processors. If you provide your own, it must supply 24VDC at 5.5 A (nominal) with a safe operating ambient temperature range of 0° to +55° C (+32° to +131° F).
  • Page 20 Flat Surface Mounting MX-U81 Hardware Guide • Do not exceed the flex radius of any connected cables. Drilling Template Mounting Hole Dimensions UNITS: mm. NOTE: If the Processor uses a Compact Flash card, mount with the Processor top facing upward so the CF card does not fall out due to vibration.

  • Page 21: Power Supply Connection

    MX-U81 Hardware Guide Power Supply Connection Power Supply Connection Warning: To avoid electrical shock, disconnect all power to the power supply before working on it. Avertissement: Pour éviter le choc électrique, débranchez toute la puissance à l'alimentation d'énergie avant de tra- vailler à...

  • Page 22: Grounding Concepts

    Grounding Concepts MX-U81 Hardware Guide Grounding Concepts Functional ground is a low impedance current path between electrical circuits and ground. It is used, for example, to improve immunity to disturbances, but is not a protective measure. Grounding deflects disturbances, but does not neces- sarily provide protection against electric shock.

  • Page 23: Usb Hardware Key

    MX-U81 Hardware Guide USB Hardware Key USB Hardware Key A USB Hardware key, which contains license and processor configuration information, is ordered and shipped separately from the processor. It must be present in the USB port labeled USB5 on the processor front before the processor is pow- ered on.

  • Page 24: Cfast Card

    CFast Card MX-U81 Hardware Guide CFast Card A CFast slot is located in the Processor front. A CFast card can be used as removable media for transferring data, perform- ing upgrades, or for extended storage. This CFast slot is connected to the chip set internally via SATA 1 with SATA III design (SATA 6 Gbit/s).

  • Page 25: Battery

    MX-U81 Hardware Guide Battery Battery WARNING: Risk of explosion if battery is handled improperly or replaced by an incorrect type. Do not recharge, disassemble, or dispose of in fire. Lithium batteries are considered hazardous waste. Dispose of used batteries according to battery maker’s instructions or in accordance with applicable local regulations.
  • Page 26 Battery MX-U81 Hardware Guide Datalogic S.r.l. 2-10...

  • Page 27: Chapter 3: Mx-U81 Cameras

    Datalogic S.r.l. does not support the use of these cameras in any manner other than described herein. MX-U81 cameras acquire an image when a signal is present on the trigger input of the camera trigger cable, then digitize images at the camera source and transmit them directly to the processor over the USB cable. These cameras provide 8-bit resolution using internal 12-bit A/D converters and some have progressive scan shutter exposure (allowing individual pixel readings).
  • Page 28 Safety Precautions MX-U81 Hardware Guide radius is fifteen times the cable diameter. It is not intended for continuous flexing or movement. Be sure that cables are safely routed away from vehicle and pedestrian traffic. • Check the intended installation area to be sure there is enough room for the camera and any lighting that may be needed.

  • Page 29: U1Xx Camera Dimensions

    MX-U81 Hardware Guide U1xx Camera Dimensions U1xx Camera Dimensions This section provides dimensions for the U1xx series of cameras. 2 x 1/4-20; 0.31 [8] deep 1.0 [25] 2 x M5 0.31 [8] deep Block Mounting holes 3 x M3 Fasteners provided 0.25 [6.3]...
  • Page 30 Mounting the Camera MX-U81 Hardware Guide 2. Turn the mounting bolts clockwise to tighten them and secure the block to the camera. 3. Use appropriately sized fasteners in the pre-threaded holes in the bottom of the mounting block to secure it to a rigid surface for proper stability and heat transfer.

  • Page 31: Connecting The Camera

    MX-U81 Hardware Guide Connecting the Camera Connecting the Camera WARNING: Never wire U1xx Camera Strobe Outputs in parallel with other U1xx Camera Strobe Outputs. This will damage the cameras. U1xx Camera Connection To connect U1xx camera trigger signals and strobe outputs, use cable 606-0674-xx (6 pin Hirose Male to DB9) with terminal block 661-0399.
  • Page 32 U1xx Camera Connection MX-U81 Hardware Guide U 1 x x C i r c u i t D i a g r a m s U1xx Trigger In Circuit WARNING: Never wire U1xx Camera Strobe Outputs in parallel with other U1xx Camera Strobe Outputs. This will dam- age the cameras.
  • Page 33 MX-U81 Hardware Guide U1xx Camera Connection U1xx Terminal Connections Datalogic S.r.l.

  • Page 34: U1Xx Camera Connection (Alternate)

    MX-U81 Hardware Guide U1xx Camera Connection (Alternate) IMPORTANT: This section describes how to connect MX-U81 cameras using the older, discrete style of terminal block. To use the newer, integrated style of terminal block, see “Connecting the Camera” on page 3-5.
  • Page 35 MX-U81 Hardware Guide U1xx Camera Connection (Alternate) U 1 x x C i r c u i t D i a g r a m s ( A l t e r n a t e ) Set Software Trigger Event to Falling Edge...
  • Page 36 U1xx Camera Connection (Alternate) MX-U81 Hardware Guide Set Software Strobe Trigger Output to Falling Edge U1xx Strobe Output circuit (sinking) U 1 x x Te r m i n a l C o n n e c t i o n s ( A l t e r n a t e ) U1xx Terminal Block Connections Datalogic S.r.l.
  • Page 37 MX-U81 Hardware Guide U1xx Camera Connection (Alternate) U 1 x x U n t e r m i n a t e d C a b l e C o n n e c t i o n s ( A l t e r n a t e )
  • Page 38 Fall Time (FT) = 0.7 us to 1.4 us Camera Setup and Calibration Use the Impact programs to setup and calibrate cameras with a MX-U81 processor. (Refer to the Camera Setup Tab sec- tion of the Impact Software Reference Guide.) Calibration insures that measurements shown in Impact software tools accurately indicate the inspected object's measure- ments.

  • Page 39: Camera Specifications

    MX-U81 Hardware Guide Camera Specifications Camera Specifications U1xx, U1xxC All U1xx cameras have the following specifications. Model numbers that end in “C” are color cameras. U1xx Common Specifications Lens Mount C mount Cabling Camera cable provides trigger and strobe. USB cable provides power...

  • Page 40: U101, U101C

    U101, U101C MX-U81 Hardware Guide U100 Specifications Power 5 VDC (2.4 W) Gain 100% to 1023% Shutter Open 16 to 1,000,000 microseconds Exposure Start Delay 17.62 μsec Software Version Impact Software V11.5.0 or greater U101, U101C This camera captures a 640 by 480 pixel size image with square pixels. It can partially scan the image horizontally and vertically.

  • Page 41: U110, U110C

    MX-U81 Hardware Guide U110, U110C U110, U110C This camera captures a 659 by 494 pixel size image with square pixels. It can partially scan the image horizontally and vertically. U110 Spectral Response (excludes lens and light source characteristics) U110 Specifications Part Number 959933001;...

  • Page 42: U150, U150C

    U150, U150C MX-U81 Hardware Guide U150, U150C This camera captures a 1296 by 966 pixel size image with square pixels. It can partially scan the image horizontally and vertically. U150 Spectral Response (excludes lens and light source characteristics) U150 Specifications...

  • Page 43: U151, U151C

    MX-U81 Hardware Guide U151, U151C U151, U151C This camera captures a 1280 x 1024 pixel size image with square pixels. It can partially scan the image horizontally and vertically. U151 Spectral Response (excludes lens and light source characteristics) E151 Specifications Part Number 959933032;...

  • Page 44: U180, U180C

    U180, U180C MX-U81 Hardware Guide U180, U180C This camera captures a 1624 by 1234 pixel size image with square pixels. It can partially scan the image horizontally and vertically. U180 Spectral Response (excludes lens and light source characteristics) U180 Specifications...

  • Page 45: U181, U181C

    MX-U81 Hardware Guide U181, U181C U181, U181C This camera captures a 1920 by 1200 pixel size image with square pixels. It can partially scan the image horizontally and vertically. U181 Spectral Response (excludes lens and light source characteristics) U181 Specifications...

  • Page 46: U190, U190C

    U190, U190C MX-U81 Hardware Guide U190, U190C This camera captures a 2048 by 1088 pixel size image with square pixels. It can partially scan the image horizontally and vertically. U190 Spectral Response (excludes lens and light source characteristics) U190 Specifications...

  • Page 47: U195, U195C

    MX-U81 Hardware Guide U195, U195C U195, U195C This camera captures a 2048 by 2048 pixel size image with square pixels. It can partially scan the image horizontally and vertically. U195 Spectral Response (excludes lens and light source characteristics) U195 Specifications...

  • Page 48: U197, U197C

    U197, U197C MX-U81 Hardware Guide U197, U197C This camera captures a 2592 by 1944 pixel size image with square pixels. U197 Spectral Response (excludes lens and light source characteristics) U197 Specifications Part Number 959933009, 959933010 Pick-up Device Progressive Scan CMOS, Rolling Shutter - 2592 (H) x 1944 (V) pixels Sensor Size 1/2.5”...

  • Page 49: U198, U198C

    MX-U81 Hardware Guide U198, U198C U198, U198C This camera captures a 2448 x 2048 pixel size image with square pixels. It can partially scan the image horizontally and vertically. U198C Spectral Response (excludes lens and light source characteristics) U198 Specifications...

  • Page 50: Third-Party Cameras

    The only other third-party cameras the MX-U81 Processor and Impact Software will support are listed in this section. This information, including power and trigger signal connections, are provided by Datalogic as a convenience.
  • Page 51 A separate power supply unit must be connected to the 12-pin connector. Note on Device Driver Install The first time you connect a JAI camera to the MX-U81 processor, you must install a device driver for the camera. To install the device driver: 1.
  • Page 52 JAI Camera MX-U81 Hardware Guide Datalogic S.r.l. 3-26...

  • Page 53: Chapter 4: Processor I/O

    C H A P T E R Processor I/O There are two versions of the MX-U processor, one with sourcing outputs - MX-U81-4-P-1, and one with sinking outputs - MX-U81-4-N-1. This section discusses the MX-U81 Processor I/O scheme. Refer to this sec- tion for all specifications when wiring your inputs and outputs into the Pro- cessor.
  • Page 54 Processor I/O Connection MX-U81 Hardware Guide Connector or terminal Color Code Signal Name number Red/White Input 14- Orange/White Input 15- Green/White Input 16- Blue/White Input Plus (Note 2) Purple/White No Connection Red/Black Output Minus (Note 1) Orange/Black Output 1 Yellow/Black...
  • Page 55 MX-U81 Hardware Guide Processor I/O Connection Connector or terminal Color Code Signal Name number Yellow Input 4- Green Input 5- Blue Input 6- Purple Input 7- Gray Input 8- White Input 9- Pink Input 10- Light Green Input 11- Black/White...

  • Page 56: Processor Inputs

    MX-U81 Hardware Guide Processor Inputs The MX-U81 Processors contain sixteen general-purpose input connections. Two inputs serve as both event and polled inputs (Inputs 1 and 2). The remaining inputs are polled. The event inputs are interrupt-driven which means that a change of state on the input will immediately cause an action and any inspection task that uses that input will run.
  • Page 57 MX-U81 Hardware Guide Input Wiring Current Sourcing (PNP) Input Circuit The diagram below shows how to wire a sensor to a general purpose or event input for model numbers containing the let- ter “P.” All inputs are compatible with current sourcing output signals. Pin 1 is the “Input Minus Common” connection for all the inputs.

  • Page 58: Processor Outputs

    All output connections must use properly grounded and shielded cable. Note: The Trigger Signal and Strobe Output for MX-U81 cameras are separate and not part of the MX-U81 Processor inputs and outputs. See MX-U81 Cameras on page 3-1 for details.

  • Page 59: Output Wiring

    MX-U81 Hardware Guide Output Wiring Output Wiring Current Sinking (NPN) Output Circuit The diagrams below show internal circuit diagrams and how to wire processor outputs for model numbers containing the letter “N.” This is an internal connection, not an output voltage source. An exter-...
  • Page 60 Output Wiring MX-U81 Hardware Guide Current Sourcing (PNP) Output Circuit The diagrams below show internal circuit diagrams and how to wire processor outputs for model numbers containing the letter “P.” This is an internal connection, not an output voltage source. An exter- nal power source must be con- nected to the Load, as indicated.

  • Page 61: Chapter 5: Cable Reference

    Ethernet An Ethernet cable (Part number 606-0457-xx) is used to connect the MX-U81 Processor to any external network. The last two digits of the part number indicate the cable length in feet. We recommend you use shielded Cat5e Ethernet cable or better to connect the Processor.

  • Page 62: Serial Port

    Display Port The display port provides DVI and HDMI video signals. USB Processor to Camera A USB 3.0 cable is used to connect the MX-U81 Processor to the U-Series camera. (USB 3.0, Micro B screw lock/A, 3 m) Datalogic S.r.l.

  • Page 63: Camera Cable

    MX-U81 Hardware Guide Camera Cable Camera Cable U1xx The terminal block and cable for connecting U1xx cameras are listed in the table below. For cable wire color codes and connection diagrams, see “U1xx Camera Connection” on page 3-5. The last two digits of the part number indicate the cable length in meters.
  • Page 64 U1xx MX-U81 Hardware Guide Datalogic S.r.l.
  • Page 65 Cfast Compact flash Connector DisplayPort USB Hardware DVI-I ethernet front power Lights status 1-10 Maintenance Monitor/panel Debounce cable Dimensions Mounting processor camera U1xx processor, flat DisplayPort connector DVI-I connector Outputs processor Ethernet cable connector Port status serial Index-1 Datalogic S.r.l.
  • Page 66 Index MX-U81 Hardware Guide Power Temperature range connection processor processor Terminal block shut down processor switch U1xx 1-10 3-24 Preventive maintenance Third-party camera Processor Top connector cable Turn off system Debounce dimensions flat mounting 3-13 U100, U100C input wiring 3-14...
