24
20
15
10
5
1
0.01
0.05

13. Customizing the Brightness Presets

Your flashlight comes with 3 brightness presets. They are referred to
as presets A, B and C. A is fully clock-wise against the stop and is the
press-and-hold preset, B is clock-wise away from the stop, C is the
counter clock-wise half of the rotary control rotation.
Follow these steps to customize a brightness preset:
• See Enabling Customization in section 11 to enable customization.
• Turn on your flashlight with the rotary control in the click on/off
position. Then select the preset you want to customize using the
rotary control.
• Triple-press-hold-release. Your flashlight will display the current
brightness level. If the current brightness level is the minimum or
maximum level, the displayed level will start with a double-blink.
• Click to move to the next brightness level. Double-click to reverse
direction and move to the previous brightness level. The menu is
circular – the last item is followed by the first and the first is
preceded by the last. When you get to the minimum or maximum
level, the displayed level will start with a double-blink.
• Note: the rotary brightness level is only available in preset C and
does not appear in the brightness menu for presets A and B.
0.1
0.5
1
5
10
13
50
100
500
