PG 1 OF 7
Assembly Instruction Packet
For: TXC71 and TXC47
Sort Boxes
Items are shipped in multible boxes
Sections needed for
Sections needed for
SOFA
LOVESEAT
box - TXC23R
box - TXC23R
box - TXC23C
box - TXC23L
box - TXC23L
TXC71
TXC47
ASSEMBLY INSTRUCTIONS
7/3/2013

Advertisement

loading
Need help?

Need help?

Do you have a question about the TXC71 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TREX TXC71

Summary of Contents for TREX TXC71

  • Page 1 PG 1 OF 7 Assembly Instruction Packet For: TXC71 and TXC47 Sort Boxes Items are shipped in multible boxes Sections needed for Sections needed for SOFA LOVESEAT box - TXC23R box - TXC23R box - TXC23C box - TXC23L box - TXC23L...

  • Page 2: Sofa Assembly

    PG 2 OF 7 Sofa Assembly Layout Parts Backs Back Cushion Seat supports Qty 3 Seats Back rails Seat Cushion Qty 3 Sideframes Center legs back legs front legs TOOLS NEEDED Layout Hardware - PHILLIPS HEAD SCREWDRIVER note: you will need hardware pack from TXC23C box 4MM HEX KEY, ALLEN, T-HANDLE (INCLUDED) QTY.
  • Page 3 PG 3 OF 7 Sofa Assembly Back Assembly Step 1 - Attach seat support to seat using Seat support (2) 3" screws. - Attach back to seat using (2) 3" screws. *Repeat this step to assemble all (3) seat assemblies Seat assembly NOTE: attach with curve side down...
  • Page 4 PG 4 OF 7 Sofa Assembly Step 4 Starting with the Right Side and Center Section, fasten the sections together using(2) 1-3/4" bolts Center back rail and (1) 3/4" bolt -These connections can be seen in greater detail below DETAIL A SCALE 1 : 10 Step 5 -Check that all bolts are completely tightened...
  • Page 5 PG 5 OF 7 Loveseat Assembly Layout Parts Back Cushion Qty 2 Backs Seat supports Seat Cushion Qty 2 Seats Back rails Sideframes Center legs back leg front leg Layout Hardware TOOLS NEEDED QTY. DESCRIPTION - PHILLIPS HEAD SCREWDRIVER A - .27 X 3" SOCKET WAFER "A" 4MM HEX KEY, ALLEN, T-HANDLE (INCLUDED) B-1/4-20 X 1-3/4 WAFER SHCS...
  • Page 6 PG 6 OF 7 Loveseat Assembly Step 1 Step 2 Attach Seat support Attach Back to Seat using (2) 3” chair screws using (2) 3” chair screws NOTE: attach with curve side down on seat frame *Repeat this for both Seat Assemblies Step 3 Attach Right Sideframe and Back rail using (4) 3"...
  • Page 7 PG 7 OF 7 Loveseat Assembly Step 4 Attach Right Side to Center Legs using (2) 1-3/4" bolts and (1) 3/4" bolt -This is easily done by correlating the components as shown Step 5 Attach Left Side to Right Side using (2) 1-3/4" bolts and (1) 3/4" bolt -Thes attachment points can be seen in greater detail below DETAIL A SCALE 1 : 8...
  • Page 8  ...
  • Page 9 Further, Poly-Wood warranties that for a period of 30-days from date of purchase all Trex Outdoor Furniture products shall be free from defects related to workmanship.
  • Page 10 Under the Trex Outdoor Furniture warranty, replacement of defective product will require the purchaser to pay for the replacement. Once the defective product is returned to Poly-Wood and evaluation confirms it is defective, credit will be issued to the purchaser.
