Hitachi CN 16SA Service Manual
Hide thumbs
Also See for CN 16SA:
- Handling instructions manual (61 pages) ,
- Handling instructions (5 pages) ,
- Handling instructions manual (8 pages)
Related Manuals for Hitachi CN 16SA
Summary of Contents for Hitachi CN 16SA
- Page 1 MODEL CN 16SA Hitachi Power Tools NIBBLER TECHNICAL DATA CN 16SA SERVICE MANUAL LIST No. 0796 Dec. 2003 SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT...
- Page 2 Hitachi Power Tools LIST NO. 0796 ELECTRIC TOOL PARTS LIST NIBBLER 2003 • • Model CN 16SA (E1)
- Page 3 PARTS CN 16SA ITEM CODE NO. DESCRIPTION REMARKS USED 957-580 TAPPING SCREW D5X30 998-033 GEAR COVER 998-008 HEX. SOCKET SET SCREW M8X20 608-VVM BALL BEARING 608VVC2PS2L 998-036 SECOND PINION AND GEAR SET 998-004 CONNECTING ROD ASS’Y 1 INCLUD. 7 993-163...
- Page 4 PARTS CN 16SA ITEM CODE NO. DESCRIPTION REMARKS USED 314-603 SWITCH (1P SOLDER TYPE) 305-499 MACHINE SCREW (W/WASHER) M3.5X6 980-063 TERMINAL 1 FOR CORD 937-631 CORD CLIP 984-750 TAPPING SCREW (W/FLANGE) D4X16 953-327 CORD ARMOR D8.8 938-051 CORD ARMOR D10.1...
-
Page 5: Standard Accessories
STANDARD ACCESSORIES CN 16SA ITEM CODE NO. DESCRIPTION REMARKS USED 990-666 HEX. BAR WRENCH 2.5MM 944-458 HEX. BAR WRENCH 4MM --- 4 --- * ALTERNATIVE PARTS 9 -- 03 Printed in Japan (030925N)
