TC Communications TC2200R User Manual

Multi-drop (bus) fiber optic modem
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TC2200R/S
MULTI-DROP
FIBER OPTIC MODEM
User's Manual
MODEL:
S/N:
DATE:
Although every effort has been made to insure that this manual is current
and accurate as of date of publication, no guarantee is given or implied
that this document is error free or accurate with regard to any specifica-
tion. TC Communications, Inc. reserves the right to change or modify
the contents of this manual at any time without prior notification.
©
COPYRIGHT 1992-2007. ALL RIGHTS RESERVED.
TC Communications, Inc. 17881 Cartwright Road - Irvine, CA 92614
Tel: (949) 852-1972
Fax: (949) 852-1948
(BUS)
Notice!
Web Site: www.tccomm.com
Email: info@tccomm.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC2200R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TC Communications TC2200R

Summary of Contents for TC Communications TC2200R

  • Page 1 TC Communications, Inc. reserves the right to change or modify the contents of this manual at any time without prior notification.

  • Page 2: Table Of Contents

    TC2200R/S Bus User's Manual Table of Contents Rev. 2.2 Chapter 1 - Overview ....................3 Description ............................3 Application Topologies ........................4 LEDs, DIP Switches and Connectors ....................5 Internal SW1 DIP Switch Functions ....................6 Single-Master Units ........................6 Multi-Master Units (Optinal) .......................

  • Page 3: Chapter 1 - Overview

    Rev. 2.2 Description The TC2200R/S and TC2201R/S are multi-drop fiber optic modems that convert electrical signals to fiber optic signals (and vice-versa). At least one TC2200 (Master) unit and one TC2201 (Slave) unit are required to communicate with each other. The Master unit is connected to a Host computer (or controller), while the Slave unit can be connected to an RTU (Remote Terminal Unit), PLC (Programmable Logic Controller) or any poll-response type device.

  • Page 4: Application Topologies

    TC2200R/S Bus User's Manual Rev. 2.2 Application Topologies The optic signal transmitted to the right (or East) side of the unit is designated as the “A” direction, while the optic signal transmitted to the left (or West) side of the unit is designated as the “B” direction.

  • Page 5: Leds, Dip Switches And Connectors

    TC2200R/S Bus User's Manual Rev. 2.2 LEDs, DIP Switches and Connectors Rx-A : (solidly lit) - The optic signal received at "RxA" BRD-1: for TC2201- Broadcast msg (Ch1) from remote Master for TC2200- Broadcast msg (Ch1) from local Host is above the sensitivity threshold BRD-2: for TC2201- Broadcast msg (Ch2) from remote Master SynA : (solidly lit) - Data packet received at optic "RxA"...

  • Page 6: Internal Sw1 Dip Switch Functions

    TC2200R/S Bus User's Manual Internal SW1 DIP Switch Functions Rev. 2.2 The internal SW1 DIP switches are used for application setup. All units are configured and tested at the factory and two are typically pre-labeled according their position in the bus (#1 is the left-end unit in the bus;...

  • Page 7: Multi-Master Units (Optinal)

    TC2200R/S Bus User's Manual Rev. 2.2 Multi-Master Units If the units were ordered for a Multi-Master Multi-Drop application (optional), the following information applies to their configuration. The Multi-Master units are (by default) DCE de- vices. The internal SW1 DIP switch functions and some features for Multi-Master units differ slightly from Single-Master models.

  • Page 8: External Sw2 Dip Switch Functions

    TC2200R/S Bus User's Manual Rev. 2.2 External SW2 DIP Switch Functions The external DIP switches (located on the front panel) are used for diagnostic testing. When SW2_1, SW2_2 or SW2_3 are in the Down position, the "ALARM" LED will 1 2 3 4 blink, indicating an abnormal condition.
  • Page 9 TC2200R/S Bus User's Manual Rev. 2.2 For 2-wire RS-485 interfaces, pins 3(-) & 16(+) are input/outputs. Figure 11. 2-wire RS-485 Connection/Logic Diagram For RS-422 and RS-485 4-wire interfaces, pins 2(-) & 14(+) are inputs while pins 3(-) & 16(+) are outputs.

  • Page 10: Rs-422 & Rs-485 Termination Resistors

    TC2200R/S Bus User's Manual Rev. 2.2 RS-422 & RS-485 Termination Resistors A termination resistor is usually necessary for RS-422 and RS-485 applications. Without proper termina- tion, the error rate of data transmission may be high due to an "echo" effect on the electrical connection.

  • Page 11: Chapter 2 - Installation

    TC2200R/S Bus User's Manual Chapter 2 - Installation Rev. 2.2 Unpacking the Unit Before unpacking any equipment, inspect all shipping containers for evidence of external damage caused during transportation. The equipment should also be inspected for damage after it is removed from the container(s).

  • Page 12: Installation Example & Rs-232 Virtual Connection

    TC2200R/S Bus User's Manual Installation Example & RS-232 Virtual Connection Rev. 2.2 To install a multi-drop bus topology, follow the example below. The SCADA Host controller is connected to the Master unit (TC2200), and four RTUs are connected to Slave units (TC2201). Notice the fiber cable from each unit's optic "TxA"...

  • Page 13: Chapter 3 - Troubleshooting

    All LEDs are Off If no LEDs are lit on the unit, check the DC power supply, terminal block connector plug, and/or the power source. If the problem persists, contact the Technical Support Department at TC Communications, Inc. Alarm LED When an alarm condition is detected, the Alarm LED will flash rapidly and one or more additional LED will flash.

  • Page 14: Chapter 4 - Bench Tests

    TC2200R/S Bus User's Manual Chapter 4 - Bench Tests Rev. 2.2 General It is highly recommended to conduct bench tests before actual installation. Bench testing allows the user to become familiar with all the functions and features of the TC2200/2201 in a controlled environment.

  • Page 15: Optic Loopback Bench Test

    TC2200R/S Bus User's Manual Rev. 2.2 Optic Loopback Bench Test Purpose: To test the broadcast (or response) and receive capabilities of a Master or Slave unit without any other units attached. Equipment Requirements: One (1) Bit Error Rate Test (BERT) Set with appropriate interface module.

  • Page 16: Local Electrical Loopback Bench Test

    TC2200R/S Bus User's Manual Rev. 2.2 Local Electrical Loopback Bench Test Purpose: To verify the DB25's cable connections, the electrical interface driver, and the receiver's Integrated Circuitry. Equipment Requirements: One (1) Bit Error Rate Test (BERT) Set with appropriate interface module.

  • Page 17: Remote Loopback Bench Test

    TC2200R/S Bus User's Manual Rev. 2.2 Remote Loopback Bench Test Purpose: To test the Slave unit's optic functions and LED indicators and to verify the integrity of the fiber optic link. When installing new Slave units in a network, a Remote Loopback test should be performed between each individual Slave and the Master unit (one at a time).

  • Page 18: Commonly Asked Questions

    TC2200R/S Bus User's Manual Rev. 2.2 Commonly Asked Questions 1. Where is the best place to begin installation for a bus topology application ? Ans: Begin with the Master unit. The first priority is to get familiar with the functions of DIP switches and LEDs.
  • Page 19 TC2200R/S Bus User's Manual Rev. 2.2 5. What is the built-in signal generator and how is it used ? Ans: By sliding SW2_3 ("SIG GEN" on the front panel) to the Down position, a pulse signal will be generated to simulate an incoming signal on the DB25's connector pins 2 & 4 (for an RS-232 interface).

  • Page 20: Chapter 5 - Component Placement

    TC2200R/S Bus User's Manual Chapter 5 - Component Placement Rev. 2.2 The TC2200/2201 is equipped with multiple DIP switches for application setup and Panel LEDs to indicate the status of electrical and optical signals. These features can ease installation and facilitate troubleshooting.

  • Page 21: Chapter 6 - Specifications

    TC2200R/S Bus User's Manual Chapter 6 - Specifications Rev. 2.2 Data Rates Async ..................... up to 38.4 Kbps Optical Transmitter ..................LED/ELED/LASER** Receiver ......................PIN Diode Wavelength ................850nm/1310nm Multimode ....................... 1310nm Single Mode Fiber Optic Connectors ..............ST* (optional FC) Loss Budget ...............

  • Page 22: Appendix A - Db25 To 2 Rj-11'S Adapter

    TC2200R/S Bus User's Manual Appendix A - DB25 to 2 RJ-11’s Adapter Rev. 2.2 Description If using the optional DB25 to 2 RJ-11’s Adapter, refer to the diagrams below for proper installation and pin connections. The DB25 to 2 RJ-11’s Adapter, separates the two independent RS-232 data channels on the DB25F.

  • Page 23: Appendix B - Warranty

    Buyer should notify TC Communications, Inc. promptly in writing of any claim based upon warranty, and TC Communications, Inc., at its option, may first inspect such goods at the premises of the Buyer, or may give written authorization to Buyer to return the goods to TC Communications, Inc., transportation charges prepaid, for examination by TC Communications, Inc.

This manual is also suitable for:

Tc2200sTc2201rTc2201s
