1. Description
The TC1200 is a compact RS-232 Fiber Optic Modem that transmits asynchronous data up to 128Kbps with
data flow controlled by RTS (request to send) and CTS (clear to send). It is a DCE only device and comes
in both Multimode (850nm/1310nm) and Single Mode (1310nm) versions. The TC1200 allows the user to plug
into a PC's COM port and, using popular communications software such as PC ANYWHERE, link two
computers together over fiber. It also works with a mouse connected to the PC's port.
2. Electrical Specifications
Interface:
RS-232
Data Rate:
Asynchronous DC to 128Kbps
Data Flow Control: XON/XOFF or RTS/CTS
Connector:
DB25 Female
Pinouts:
2
Tx Data:
Transmit Data
3
Rx Data:
Receive Data
4
RTS:
Request To Send
5
CTS:
Clear To Send
6
DSR:
Data Set Ready
20
DTR:
Data Terminal Ready
8
DCD:
Data Carrier Detect (Optic Signal Detect)
1
FGND:
Frame Ground
7
SGND:
S i g n a l G r o u n d
3. Optical Specifications
Transmitter:
LED/ELED; typical Launch Power:
Receiver:
PIN Diode; typical Sensitivity:
Loss Budget:
850nm/1300nm MM, @62.5/125µm: 15dB
1300nm Single Mode, @9/125µm: 20dB
Distance:
850nm Multimode, @62.5/125µm:
1300nm Multimode, @62.5/125µm: up to 4km distance*
1300nm Single Mode, @9/125µm: up to 30km distance*
Wavelength:
850nm Multimode
1300nm Multimode
1300nm Single Mode
Connector:
ST
FC
*Launch power, sensitivity and distance are listed for reference only. These numbers may vary.
4. Power Requirements
The TC1200 is designed to draw power from the power jack only and consumes very low power. The input
DC voltage is from 12Vdc and current is @150mA. The connector is a terminal block type with polarity
indicated on the top cover of the unit. Should the external power adapter need to be replaced, use one with
the following specifications: 12VDC @800mA. You may order it from TC Communications.
5. Physical Characteristics
Height:
0.75" (1.91 cm)
Width:
4.0" (10.16 cm)
TC1200
RS-232 Async (with Control) Fiber Optic Modem
User's Manual
TC Communications, Inc.
Tel: (949) 852-1972
To
DTE device
Frame GND
Signal GND
-19dBm* (850nm/1300nm Multimode, @62.5/125µm)
-14dBm* (1300nm Single Mode, @9/125µm)
-34dBm* (850nm/1300nm Multimode, @62.5/125µm)
-34dBm* (1300nm Single Mode, @9/125µm)
up to 3km distance*
(Model TC1200-01-XX-XX-12)
(Model TC1200-03-XX-XX-12)
(Model TC1200-L1-XX-XX-12)
(Model TC1200-XX-ST-XX-12)
(Model TC1200-XX-FC-XX-12)
Depth:
2.4" (6.10 cm)
Weight:
7 oz. (137 gm)
© COPYRIGHT 1992-2009. ALL RIGHTS RESERVED.
17881 Cartwright Road. Irvine, CA 92614
Fax: (949) 852-1948
Web Site: www.tccomm.com
-1-
TC1200 User's Manual
Rev. 2.1
TC1200
DCE
Tx Data
2
Rx Data
3
RTS
4
CTS
5
DSR
6
DTR
20
DCD
8
SYNC
1
7
Email: info@tccomm.com
