Pacific CarryMe Owner's Manual

Owner manual
Seat post
Seat stay
Rear carrier (optional)
Trolly wheels
Rear wheels
Step 3:
Rotate the seat tube QR lever up and out from
behind the QR Hook on the frame. Open the QR
Lever on the seat tube, insert the seat post and
close the QR lever.
Note:
Do not raise the seat higher than the minimum insertion mark.
Step 6:
Open the QR lever on top of the stem, raise the
stem to desired height, and close the QR lever.
How to fold
Step 1:
Loosen the head tube clamp bolt one turn, slide the
head tube clamp to top by pushing the seat
backward, latch the head tube to the frame.
You are now ready to pull/push it or carry it!
Extension
stem
QR lever
Saddle
Stem
Seat clamp QR
Seat tube
Headtube
Seat clamp
QR hook
Spring latch
(underneath the frame)
Crank set(STD)
Foldable pedal
Speed Drive(DS)
Step 4:
Swing the seat tube backwards. Lock the seat stays
to the seat tube.
Step 7:
Install the pedals. Turn the right pedal clockwise
and the left pedal counterclockwise to tighten.
Step 2:
Un-lock the seat stays from the seat tube, pull the
seat toward the handlebar, open the seat QR lever,
lower the seat and turn it side-ways, latch the QR
lever to the frame.
Important Safety Checklist!
Check and make sure that all clamps are properly tightened.
1) The handlebars should be tight with no play.
Don'ts!
2) The head tube clamp should be fully tightened not allowing rotation or play.
• Don't exceed the maximum
3) The seat stay clamp should be fully tightened (step 4).
load limits.
4) The seat post clamp should be fully tightened not allowing any rotation or sliding.
• Don't carry a person or a pet
Do not raise the handlebar stem and seat post up beyond the maximum insertion mark.
on the rear carrier.
Always wear a helmet and abide by all traffic regulations and courtesies!
• Don't perform stunt riding.
Rear carrier max. loading: 10kg / Average speed: 13km/h
• Don't jump over curves.
Max. height: 185cm / Max. loading: 80kg
• Don't raise the handlebar
Important Maintenance Checklist!
stem beyond the height
1st service inspection after at most 300 km or at latest one months after purchase,
limit.
• Don't raise the seat post repeat every 3 months.
Parts need lubrication: chain, headset, bearings.
beyond the height limit.
• Don't over stress any of the Parts prohibit lubrication: seatpost, seat tube, adjustable stem, rims.
QR levers. Repeat lubrication every half month or after at most 150 km ride.
• Don't ride it off-road.
Apply lubrication immediately after washing or riding in rainy day.
Handlebar
Front carrier /
Bottle cage adaptor
mount
Headtube clamp
Front wheel
Seat stay clamp
-
Assembly Procedures
Step 1:
Unpack the box – a 95% assembled bike, a seat
assembly, and a pair of pedals.
Step 2:
Stand the bike up on its rear wheel and trolley
wheels. Insert both handlebar ends into the center
tube, close the QR levers.
sa
Step 5:
Open the spring latch, slide the head tube clamp
toward the bottom of the head tube, and tighten
the wing bolt with your fingers.
Step 8:
Adjust the height and alignment of handlebar
and seat.
Note:
Do not raise the seat
higher than the
minimum insertion mark.
Step 3:
Open the stem QR lever, lower the stem and turn
the handlebar sideways, close the QR lever.
Step 4:
Fold the pedals.
