Hydrofarm Digital Light Meter
This compact light meter offers accurate representation of different light intensities displayed
in footcandles. This instrument is excellent for monitoring the light output of grow lamps to
ensure optimal performance from the garden or greenhouse. Automatic zero calibration, an
easy to read LCD display, a low battery indicator, and remote photo sensor make taking
measurements easy and convenient.

Specifications:



Model:
Display:

Range:

Sampling Time:

Operating Temperature:

Operating Humidity:

Dimensions:

Battery:


Instructions for Use:
1. Turn the meter on and place the photo sensor parallel to the ground so that the white cell faces
up towards the light source.

2. Adjust the foot candle switch between the x1, x10, and x100 settings to find the proper reading.
The display will reach a maximum point and display "1" if the measured light source is too
intense and one or more zeros if a lower setting is needed. At this point adjust the switch to a
higher or lower setting so that an accurate reading may be obtained.

3. Multiply the number on the display by whichever setting is used i.e. x1, x10, and x100. The
product is the amount of foot candles at the location of the photo sensor.

Replacing the Battery:
1. Make sure the power switch is in the "OFF" position.

2. Slide the cover off of the unit in the direction indicated by the "OPEN" arrows.






















LG17010


13mm (.5") LCD


0 – 5000 footcandles


.4 seconds


32 – 104 degrees Fahrenheit


< 80%


2.9"L x .9"W x 4.3"H


9 volt

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LG17010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hydrofarm LG17010

  • Page 1: Specifications

    Hydrofarm Digital Light Meter   This compact light meter offers accurate representation of different light intensities displayed  in footcandles. This instrument is excellent for monitoring the light output of grow lamps to  ensure optimal performance from the garden or greenhouse. Automatic zero calibration, an  easy to read LCD display, a low battery indicator, and remote photo sensor make taking  measurements easy and convenient.   Specifications:     Model:              LG17010  Display:            13mm (.5”) LCD    Range:             0 – 5000 footcandles    Sampling Time:          .4 seconds ...
  • Page 2   3. Carefully remove the battery from the housing and detach it from the terminals.    4. Replace it with a new battery and return the cover back to the compartment.    Warnings:  • Avoid contact with liquids. Failure to do so could cause permanent damage to the  display and other electrical components.    • Do NOT take the light meter apart.    • Keep out of reach of children.                            The Hydrofarm Guarantee   The Hydrofarm Digital Light Meter is guaranteed to the original owner for 1 year from the date  of purchase. Misuse, abuse, or failure to follow instructions is not covered. If you have a  problem, recheck your battery source and compartment. If this does not remedy the situation,  contact the original place of purchase for a warranty assessment. Unauthorized returns will not    be accepted. Save your receipt/invoice – a copy is required for all warranty work.
