MultiChannel MEA210-System Installation Manual

6

Connection of the Peristaltic Perfusion System PPS2

Perfusion Out (from MEA)
Perfusion In
Waste Bottle
(via PH01)
1. Connect the PPS2 with the power supply
unit to the power outlet.
2. Connect the PPS2 with the USB cable A-B
to the computer for PPS2 software control
(possible via an USB hub).
Perfusion Solution
3. Connect the tubes of the PPS2 to the
perfusion solution, the PH01, the perfusion
out and the waste bottle. Please follow the
instructions on the leaflet in the tube bag.
Adjust the flow rate.
USB 2.0 Port
USB 2.0 Cable A-B
Power Outlet
Power Supply
Unit
7

Test of the System and Preparation for Experiment

120MEA-SG
60MEA-SG
MEA Signal Generator: The 60-, 120- or 256MEA Signal Generator is used for setting up an experiment with
sample data for training, controlling, and troubleshooting purposes. Please insert the signal generator (orientation:
you can read the "ON" and "1 2" on the switch) and test your system with this artificial data and make yourself
comfortable with the software settings before starting an experiment with biological samples.
You can find the instructions for the signal generators in its bag, on the provided USB stick (Manuals/MEA_Signal_
Generator_Manual.pdf) or online at www.multichannelsystems.com/downloads/documentation.
When working with biological samples, please insert the MEAs in correct orientation.
Important: MEAs are not symmetrical! Standard MEAs with one big internal reference
electrode should be placed with the reference electrode to the left side in the headstage.
Otherwise, the MEA layout will not match with the pin layout of the channel map in the
data acquisition programs from MCS. For the orientation of special MEAs, please read
the respective datasheet. You can find instructions for the handling of the MEAs on the
provided USB stick (Manuals/MEA_Manual.pdf) or online. Datasheets for each MEA type
are available online at www.multichannelsystems.com/products/microelectrode-arrays.
PPS2 Rear Panel
256MEA-SG
In Case You Experience any Problems
1. Consult the manuals provided on the included USB stick or online
at www.multichannelsystems.com/downloads/documentation.
2. If you do not find help in the manuals, please do not hesitate
to contact our support team via:
- Email: support@multichannelsystems.com
- Our support form at
http://www.multichannelsystems.com/service/support.
3. In order to keep your software up-to-date and stay tuned to all
MCS news, please subscribe to our newsletter via our web site
("Subscribe Newsletter").
We hope that your setup was successful and you can now start your
experiments.
We wish you great progress with your research and are happy to help
you with any further questions!
Your MCS team
Multi Channel Systems
MCS GmbH
Aspenhaustraße 21
© 2018
72770 Reutlingen
Multi Channel Systems MCS GmbH
Germany
Product information is subject to change without notice.
Phone +49-7121-909 25 25
Products that are referred to in this document may be
Fax +49-7121-909 25 11
either trademarks and/or registered trademarks of the
support@multichannelsystems.com
respective owners. The publisher and the author make no
claim to these trademarks. www.multichannelsystems.com
