  • Page 1 Wireless2100-System Manual...
  • Page 2 Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted without the express written permission of Multi Channel Systems MCS GmbH. While every precaution has been taken in the preparation of this document, the publisher and the author assume no responsibility for errors or omissions, or for damages resulting from the use of information contained in this document or from the use of programs and source code that may accompany it.

  • Page 3: Table Of Contents

    TABLE OF CONTENT ABOUT THIS MANUAL ........................... 4   WELCOME TO THE WIRELESS2100-SYSTEM ..................5   IMPORTANT SAFETY ADVICE ........................ 6   ......................... 7   PERATOR BLIGATIONS ......................... 7   UARANTEE AND IABILITY SYSTEM COMPONENTS ......................... 8   2100 H ........................

  • Page 4: About This Manual

    About this Manual This manual comprises all important information about the first installation of the hardware and software and about the daily work with the instrument. It is assumed that you already have a basic understanding of technical and software terms. No special skills are required to read this manual. If you are using the device for the first time, please read the important safety advice before installing the hardware and software, where you will find important information about the installation and first steps.

  • Page 5: Welcome To The Wireless2100-System

    For data acquisition and analysis, the easy to use software package MC_Rack is included. Headstages are available with 4, 8, 16 or 32 channels. Each Wireless2100-System can operate with any type of headstage. With its excellent signal-to-noise ratio, adjustable sampling rate and wide frequency range, the W2100-Systems are a versatile solution for spikes, LFP, EEG, ECG, and ECoG.

  • Page 6: Important Safety Advice

    Important Safety Advice Warning: Make sure to read the following advice prior to install or to use the device and the software. If you do not fulfil all requirements stated below, this may lead to malfunctions or breakage of connected hardware, or even fatal injuries. Warning: Obey always the rules of local regulations and laws.

  • Page 7: Operator's Obligations

    Operator's Obligations The operator is obliged to allow only persons to work on the device, who  are familiar with the safety at work and accident prevention regulations and have been instructed how to use the device;  are professionally qualified or have specialist knowledge and training and have received instruction in the use of the device;...

  • Page 8: System Components

    Wireless2100 Headstages The headstage is the first of the three elements of the Wireless2100-System. The headstages are small and lightweight to allow recordings in freely moving animals. Headstages are available with 4, 8, 16 or 32 channels.

  • Page 9: Sampling Rate

    Sampling Rate The Wireless2100-System can sample the maximum of 32 channels with 10 kHz per channel. Depending on the number of selected channels, the sampling rate can be increased even more. If multiple headstages are operated simultaneously with a single receiver, the sampling rate is limited to 2 kHz per channel. For details please see chapter "Technical Specifications"...

  • Page 10: Modules For Additional Functions

    The standard battery (100 mAh) of a headstage permits continuous recording of all channels for more than 2 hours. Empty batteries can be replaced without removing the headstage, and recharged while the experiment can be continued with a second battery. Modules for additional Functions W2100 headstages have a modular design.

  • Page 11: Wireless2100 Receiver

    Wireless2100 Receiver The receiver is the second element of the Wireless2100-System. One receiver of the Wireless2100-System can receive the digitized signals sent from up to four headstages. Four antennas are used for data transmission, one antenna submits control signals to and from the headstage.

  • Page 12: Wireless2100 Interface Board

    The power LED near to the MCS logo on the front panel of the interface board should light up when the Wireless2100-System is "ON", and the device is connected to the power line. If not, please check the power source and cabling.
  • Page 13 The device is switched "OFF" when the toggle switch is switched to the right. If the Wireless2100-System is "ON", and the device is connected to the power line, the power LED on the front panel of the interface board should light up. If not, please check the power source and cabling.
  • Page 14 Analog Channels Eight Analog IN channels are available via 20 pin connector. Please read chapter "Pin Layout" (Analog IN Connector) in the Appendix for more information. The additional analog inputs are intended for recording additional information from external devices, for example data from a microphone Two of the eight analog channels (analog channel 1 and 2) are directly accessible via two Lemo connectors.

  • Page 15: Accessories

    Accessories Default accessories of the Wireless2100-System are the signal generator, the remote control to reactivate the headstage, and the USB charger for the battery. ME/W-Signal Generator The ME/W-System Signal Generator can generate a number of pre-defined sine waves and artificial biological waveforms and feed it into all types of headstages.

  • Page 16: System Setup

    Be careful when using a Virus Scanner. These programs are known to disturb MC_Rack, and even data loss may occur. When using a Wireless2100-System it is recommended to connect a high performance computer with a separate hard disc for program files and data storage. The provided possibility to make long term experiments with a sample rate of up to 40 kHz needs high memory capacity.

  • Page 17: Wireless2100 Hardware Setup

    Connect the interface board with a USB2.0 port of a computer where MC_Rack is already installed. Avoid USB 3.0 ports (USB 3.0 ports are blue). Do not use USB hubs.  Switch on the Wireless2100-System on the interface board. LEDs on the interface board and receiver should light up. ...
  • Page 18 Click "Configuration" in "Source Layout". Enable the check box "Digital Input Channel" if you want to display external TTL signals, fed into the Wireless2100-System via Lemo connectors on the interface board. Deselect the check box, if you do not need additional digital channels.
  • Page 19 „Wireless” Window of Hardware Tab The additional “Wireless” control panel is an extension of the hardware tab, which is only visible if a Wireless2100-System is connected. Click button "Scan" to see all available headstages. Headstages are only available for the system if the battery is connected, if they are within transmitting range, and have not been switched off previously by software command.
  • Page 20 In this tab "Infos" about the connected Wireless2100-System are listed. Click the "Audio" tab of the dialog. On the interface board of the Wireless2100-System you can connect an audio system "Audio OUT" (3.5 mm phone jack) to make the electrical activity audible. This audio output is real-time. Headphones or a speaker can be connected directly to the Audio OUT.

  • Page 21: Operating Multiple Headstages

    Operating multiple Headstages It is possible to operate different headstages connected to one Wireless2100-System. The headstages are discriminated via frequency band for the radio communication. Each headstage is labelled by the type (W16) and the serial number (S/N 1230). Please see the bill of delivery for the assignment of the...

  • Page 22: Sequential Recordings

    Sequential Recordings After pressing the button “Scan” the receiver scans for available headstages in range. Then the user is able to select the desired headstage. Click on one of the headstages in the "Available Headstages" window and press the button "Select". After recording from the first headstage, deselect the headstage by clicking the button "Deselect".

  • Page 23: First Functional Tests

    Set up the Wireless2100 hard- and software as described above. Make sure all components are connected and the Wireless2100-System is switched on at the interface board. Connect a charged battery and the ME/W-Signal Generator to your headstage. See the ME/W-Signal Generator datasheet in the Appendix for details on connector and orientation.

  • Page 24: Experimental Setup

    Experimental Setup First step to set up an experiment with the Wireless2100-System is to implant an electrode into the laboratory animal. The electrode has to be fixed to the skull, for example with dental cement, to guarantee a stable positioning of the electrode in the desired area of the brain. The electrode connector must be available on the skin surface of the animal.
  • Page 25 When external interferences, for example heartbeats, muscle potentials, breathing, disturb the measurements, both, the recording and the reference electrodes measure the same disturbance and the noise signal is removed because only the difference between recording and reference electrode is digitized and transmitted (Common Mode Rejection).

  • Page 26: Troubleshooting

    Please do not use, for example, a mobile phone equipped with blue tooth or a WLAN connection or a microwave in the vicinity of headstage and receiver otherwise it may cause trouble in data transfer. Important: For bandwidth reasons it is not recommended to use an USB hub to connect the Wireless2100-System to your computer.

  • Page 27: Technical Support

    The software of MC_Rack version you are currently using. On the "Help" menu, click "About MC_Rack". The displayed dialog box shows the version number.  The hardware version of the Wireless2100-System you are currently using is displayed in the “Hardware” tab of the starting dialog. ...

  • Page 28: Appendix

    Appendix Technical Specifications The Wireless2100-System is a 4-, 8-, 16- or 32-channel wireless in vivo system with headstage, receiver and interface board. Analog signals are converted in digital data streams in real-time. Warning: The devices may only be used together with Wireless2100-Systems from Multi Channel Systems MCS GmbH, and only for the specified purpose.
  • Page 29 Amplifier integrated in the headstage Bandwidth 1 Hz to 5 kHz (0.1 Hz on request) Resolution 16 bit Input voltage range + / - 12.4 mV Sampling Rate Number of selected channels Sampling rate in kHz/channel W2100-HS4 W2100-HS8 W2100-HS16 W2100-HS32 Max.
  • Page 30 Receiver Dimensions (W x D x H) 110 mm x 78 mm x 29 mm Frequency band 2.4 GHz Impedance of antennae 50 Ohm Interface Board Dimensions (W x D x H) 110 mm x 78 mm x 29 mm Control interface USB 2.0 High Speed Software...

  • Page 31: Pin Layout Of The Interface Board

    Pin Layout of the Interface Board W2100 Interface Board: 20-Pin Connector (Analog IN) 20-Pin Connector for Analog IN and DSP Pin 1 Pin 2 TRST Pin 3 Pin 4 Pin 5 Pin 6 Pin 7 Pin 8 RTCK Pin 9 Pin 10 Pin 11 Pin 12...

  • Page 32: W2100 Interface Board: Digital In / Out Connector

    W2100 Interface Board: Digital IN / OUT Connector 68-Pin MCS Standard Connector Pin 1 GNDP (power ground) Pin 2 GNDS (signal ground) Pin 3 - 10 Digital output channels bit 0 - 7 GNDS (signal ground) Pin 11 - 14 Pin 15 - 22 Digital output channels bit 8 - 15 Pin 23 - 26...

  • Page 33: Datasheets

    Datasheets...

  • Page 34: Contact Information

    W2100-HS4-Headstage Pin Layout of the 4-Channel Headstage for the Wireless2100-System W2100-HS4 top side: W2100-HS4-Headstage bottom side: Please use the connector in the lower Connector for the electrode probe right (storage battery) for orientation or for the ME/W-Signal generator.
  • Page 35 W2100-HS4-Headstage Technical Specifications W2100-HS4-Headstage Number of channels Dimensions (W x D x H) 13 x 13 x 5 mm (w/o antennae) Weight (w/o battery) 2.5 g Amplifier integrated in the Headstage Bandwidth 1 Hz to 5 kHz (0.1 Hz on request) Input impedance 1 G|| 10 pF...
  • Page 36 W2100-HS8 Headstage Pin Layout of the 8-Channel Headstage for the Wireless2100-System W2100-HS8 top side: W2100-HS8 bottom side: Please use the connector in the lower Connector for the electrode probe right (storage battery) for orientation or the ME/W-Signal generator.
  • Page 37 W2100-HS8 Headstage Pin Layout of the 8-Channel Headstage for the Wireless2100-System W2100-HS8 bottom side: W2100-HS8 top side: Connector for the electrode probe Please use the connector in the lower or the ME/W-Signal generator. right (storage battery) for orientation of the headstage.
  • Page 38 W2100-HS8 Headstage Technical Specifications W2100-HS8 Headstage (Omnetics or single row connector) Number of channels Dimensions (W x D x H) 15.5 x 15.5 x 5 mm (w/o antennae) Weight (w/o battery) 2.8 g with Omnetics connector 3.1 g with single row connector...
  • Page 39 W2100-HS16 Headstage Pin Layout of the 16-Channel Headstage for the Wireless2100-System W2100-HS16 bottom side: W2100-HS16 top side: Connector for the electrode probe Please use the connector in the lower or the ME/W-Signal generator. right (storage battery) for orientation of the headstage.
  • Page 40 W2100-HS16 Headstage Technical Specifications W2100-HS16 Number of channels Dimensions (W x D x H) 15.5 x 15.5 x 5 mm (w/o antennae) Weight (w/o battery) 2.9 g Amplifier integrated in the Headstage Bandwidth 1 Hz to 5 kHz (0.1 Hz on request) Input impedance 1 G|| 10 pF...
  • Page 41 W2100-HS32 Headstage Pin Layout of the 32-Channel Headstage for the Wireless2100-System W2100-HS32 bottom side: Connector for the W2100-HS32 top side: electrode probe or the ME/W-Signal generator. Please use the connector in the lower right (storage battery) for orientation of the headstage.
  • Page 42 W2100-HS32 Headstage Technical Specifications W2100-HS32 Number of channels Dimensions (W x D x H) 15.5 x 15.5 x 6.7 mm (w/o antennae) Weight (w/o battery) 3.7 g Amplifier integrated in the Headstage Bandwidth 1 Hz to 5 kHz (0.1 Hz on request) Input impedance 1 G|| 10 pF...
  • Page 43 Contact Information Local retailer Please see the list of official MCS distributors on the MCS web site. User forum User Forum The Multi Channel Systems provides the opportunity for you to exchange your experience or thoughts with other users worldwide. Mailing list If you have subscribed to the Mailing...
