LI4278 LINEAR IMAGER
BEEPER INDICATIONS
Standard Use
Low/medium/high beep
Short medium beep
4 long low beeps
Power up
Bar code decoded
Transmission error detected;
data is ignored
Parameter Menu Scanning
High/low/high/low beep
High/low beep
Successful
Correct programming
parameter setting
sequence performed
Wireless Operation
High/low/high/low beep
High/low beep
Pairing bar code
Bluetooth
scanned
disconnection
Scanner not working
No power to scanner
Scanner is disabled
Check system power; battery may be discharged;
Ensure that correct host
charge scanner in cradle; check battery door is closed;
interface cable is used
ensure battery end cap is secured
Scanner decoding bar code, but data not transmitting to host
Scanner not programmed for
Scanner not paired to
Interface cable is loose
correct host interface
host-connected interface
Scan appropriate host
Pair the scanner to
parameter bar codes
the cradle
LED indicates low battery start-up
Low battery start-up
Cradle communication error
Wait for red LED to turn green
Inspect contacts; remove and reinsert
indicating scanner is charging
scanner in cradle
RECOMMENDED USAGE GUIDE - OPTIMUM BODY POSTURE
Avoid Extreme Wrist Angles
AVOID EXTREME
WRIST ANGLES
