Nyrius ARIES NAVS502 Quick Start Manual

(NAVS502)
QUICK START GUIDE
01

RECEIVER

02

TRANSMITTER

Optional TV output
Optional second
HDMI source
HDMI HDMI
For additional product information, please consult the manual at:
03
IR EXTENDER SETUP
Top view
DEVICE
30° 30°
5-10cm
IR sensor must be in front
of IR window of device.
DEVICE 1 DEVICE 2
NYRIUS.COM/SUPPORT
BASIC OPERATION
01
IR INFO
C
A
D
B
INPUT
02 02
POWER ON POWER ON / ALIMENTATION ON
IR INFO
OR
INPUT
Allow 8-10 seconds to connect
03
HDMI
Select HDMI from your TV's Select HDMI input 1 or 2 by using
source/input menu the input button on your remote
* Obstacles may decrease transmission distance. Interference may come from other wireless devices using 5GHz band.
Power
A
Turns transmitter / receiver ON / OFF
B IR
Press if remote extender is unresponsive
C Info
Displays current system settings
D Input
Cycles through audio / video sources
HDMI 1
IR INFO
INPUT
Ensure the Aries Unit is on the
correct input source, on both your
or transmitter/receiver TV, and Aries unit
