QUICK START GUIDE v 1.2
WHAT'S INCLUDED
Receiver
Transmitter And
Protective Cap
Quick Start Guide
Power Adapter
IR Emitter
LIFETIME
CUSTOMER
SUPPORT
Lifetime Customer
Support
Thank you for your purchase of this
Nyrius product. We hope you enjoy your
experience. If you have any questions
please visit us at www.nyrius.com/support
Since its inception Nyrius has been
a leader in developing innovative
connectivity solutions. Our products have
been enchanting home entertainment
enthusiasts and business professionals
through exceptional product design, high
performance, and outstanding customer
service. At Nyrius, our mission is a simple
one – create people-driven products that
HDMI Cable
IR Receiver
1 Year Warranty
ORION PRIME (TS52)
Antennas X 2
Right Angle
Adapter
USB Power Cable
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Nyrius ORION PRIME
Summary of Contents for Nyrius ORION PRIME
- Page 1 Our products have been enchanting home entertainment enthusiasts and business professionals through exceptional product design, high performance, and outstanding customer service. At Nyrius, our mission is a simple one – create people-driven products that WHAT’S INCLUDED Receiver Power Adapter...
- Page 2 FIRST TIME SETUP Connect the 2 antennas to the Receiver. Connect power adapter to the Receiver. Connect the Receiver to the TV with the HDMI cable. HDMI HDMI Connect Transmitter to HDMI output on computer and plug in power cord to USB port on the computer. Once connected the status LED will turn blue.
- Page 3 Orion Prime, some computers do not support all. Please check your computer manual for details on display options. Note: The Orion Prime has less than 200ms of latency, which can affect mouse/ controller input on computers.
- Page 4 IR EXTENDER SETUP What is an IR Extender Cable? The Orion Prime comes with an IR Receiver and IR Emitter that allows you to control your source device with its remote from the Receiver’s location. The remote’s IR signal is transmitted by the Receiver to the Transmitter and then through the IR Emitter to the source device.
- Page 5 Does this device support multiple receivers and transmitters? The Orion Prime supports up to two receivers connected at the same time but can only be connected to one transmitter at a time. Additional receivers are available at www.nyrius.com.
- Page 6 FCC CAUTION: the user’s authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. For operation with 5150 - 5250GHz (5470-5725GHz frequency range, it is restricted to indoor environment. The band from 5600-5650MHz will be disabled by the software during the manufacturing and cannot be changed by end user.
- Page 7 This warranty does not cover the shipping cost, insurance, or any other incidental charges. Products shipped for warranty service must be pre-paid by the customer, and Nyrius will cover the cost to ship the repaired or replaced product back to the customer.
- Page 8 Questions? Give us a chance to help, we’re just a click away nyrius.com/resources nyrius.com/videos nyrius.com/support nyrius.com/contact Don’t forget to register your product with us! nyrius.com/registration...
