NAUTICAST A2 Installation Manual

This installation guide serves as a complement to the
product manual (Art.No. 1001001-2), included on the
Nauticast Data Card (USB-Stick).
Nauticast A2 AIS System should always be planned
and executed by authorized personnel.
Please visit our web-site for the latest information
regarding the Nauticast A2. www.nauticast.com
RECOMMENDED PHYSICAL INSTALLATION
Transponder unit should be mounted in a protected area and compass
safe distances kept in mind (see table on the right). VHF antenna must be
mounted vertically, free of reflective objects, minimum distance to other
VHF antennas 1.5m and out of the radar beam. GPS antenna must have
an omnidirectional view of the sky for ideal reception.
SYSTEM MODE
Important: The Nauticast A2 can operate in two different system modes,
Class A mode (default) and Inland mode.
Inland mode is applicable to European river going vessels. Set mode in:
Main Menu Config System Settings System Mode
Instructions only relevant for Inland AIS operation will be in
brown print.
Installation Guide
Installation of the
Physical
Nauticast A2
Size W x H x D: 238x87x173 (mm)
Gimbal Mount
Size W x H x D: 252x95x65 (mm)
Power
Input 12/24 VDC
Power Consumption: 20W (60W peak)
Required power on current: 4A
GPS Receiver (AIS internal)
Receiver: 50 CH
Frequency: L1 (1575.42 MHz)
Update Rate: 2 Hz
Position accuracy (SA off)
Position <2.0 m DGPS (CEP, 50%)
Position <2.5 m GPS (CEP, 50%)
Antenna feeding: 5 VDC
Electrical Interfaces
RS 422 Port Default speed (bps)
Pilot In/Out 38400
ECDIS In/Out 38400
LR In/Out 9600
Sensor 1 In 4800
Sensor 2 In 4800
Sensor 3 In 4800
RS 232 Port Default speed (bps)
RS232 In/Out 38400
Signal connector: 26 pin HD-SUB (M)
RS-232 connector: 9 pin D-SUB (M)
Power connector: 4 pin ConXall (M)
GPS 50 ohm antenna connector TNC female
VHF 50 ohm antenna connector BNC female
Chassis GND screw size: M6
Cables (recommended)
VHF and GPS RG214/U
Sensors e.g. Gyro RFE-HFI 2x2x0.75 mm
1001001-3
Blue Sign Installation
Install Resistor connecting brown and orange
wires:
12V: 2.2kΩ
24V: 10 kΩ
VHF Transceiver
Frequency 156-163 MHz
Output power 1/12.5 W
Channel bandwidth 25 kHz
Bit Rate 9600 bps
Intervals between position reports 1-180 s
Modulation FM-GMSK/GFSK
Transmitter 1
Receivers 3
Transceiver Sensitivity <-107 dBm
Environmental data
Protected environment (IEC 60945)
Operating temperature -15 °C to 55 °C
Compass safe distance
60 cm to standard magnetic compass
45 cm to steering magnetic compass
The Nauticast A2 AIS System is compliant
with the following Standards
IMO Performance Standard for AIS (MSC 74(69)
Annex 3)
ITU-R M. 1371-5
ITU-R M. 825-3
ITU-R M. 1084-5
IEC 61993-2 Edition 2
IEC 61162-1/2 Edition 4 (NMEA 0183, Version 4.0)
IEC 61108-1 Edition 2
IEC 60945 Edition 4
IEC 62288 Edition 2
IALA Guidelines on AIS
Inland Test Standard Ed. 2.0
Specifications subject to change without notice
