- Page 1 INSTALLATION GUIDE Isodrive 3200 Revision V1.1 HOME APPLIANCES www.schweigen.com.au...
-
Page 2: Table Of Contents
Flexible Ducting __________________________________________________________________________ 14 Shallow Roof Space ______________________________________________________________________ 15 Important Note ___________________________________________________________________________ 15 Securing Flexible Duct ____________________________________________________________________ 16 7. Parts List Parts List for Isodrive 3200 __________________________________________________________________ 17 8. Maintenance Roof Restoration or Cleaning ______________________________________________________________ 19 9. Warranty/Disclaimer _______________________________________________________________________________________ 19 Page 2... -
Page 3: Welcome
This will ensure your personal safety and the lasting value of your Isodrive system. We trust that you will enjoy your new Schweigen Isodrive system. Please always retain your proof of purchase to aid in any warranty queries. -
Page 4: Your Safety
Children should be supervised to ensure that they do not play with the appliance: it is not a toy. Do not install Isodrive motor to a non-Schweigen and/or non-silent rangehood. If you do so, your warranty will be voided. -
Page 5: Motor Features
See installation instruction notes ‘Why flexi-duct’. Recommended Installation Distance Isodrive 3200 motor, recommended 4 to 5 metres of flexi ducting. NOTE: Although less than 4 to 5 metres will increase extraction power this will result in higher noise level. -
Page 6: Minimum Mounting Height
Any installation problem must be reported to Schweigen. Call outs relating to incorrect installation will result in a service fee direct to the customer. Schweigen takes no responsibility for problems caused by faulty installation, this may void warranty. -
Page 7: Description
3. Description Isodrive Motor Included in the box: Power Cord 1. Isodrive 3200 motor (450W x 290H mm approx.) Pipe protrusion above 50mm dektite 250mm PVC Pipe Approx. 3 metre, 10amp cable and standard male plug Dektite Fix pipe to fan module with side locking screws 2. -
Page 8: Installation
4. Installation 3200 motor Power Cord Pipe protrusion above 50mm dektite 250mm PVC Pipe Dektite Fix pipe to fan module with side locking screws Fit side supports to locate pipe Strap to supports 250mm flexible duct (Minimum 4 metres ducting length fully extended) Note : Prevent any cord bunching by... -
Page 9: Roof Installation
Please be aware that the 3200 motor is capable of expelling air at 3200m /hr. For more information on environmental noise limit and conditions please contact your local Council. We have a list of recommended installers available on the Schweigen website. Page 9... -
Page 10: Through Wall Installation
4. Installation THROUGH WALL INSTALLATION Through Wall Installation Minimum portrusion distance from wall Recommended to fix pipe to a support Connecting pipe structure or strapping bracket (not included in mounting kit). Wall Power cable Mounting points Ensure power cable, pipe and Wall cover plate cover plate slot is at the bottom. - Page 11 4. Installation Protrude pipe to distance (use as reference only) Mounting points Marked fastening holes Fix pipe to structure or with Ensure slot cover plate, first before installing a strapping bracket. power cable and pipe slot is at the bottom. Install fan unit last Wall cover plate (Optional - Part Number P2025)
-
Page 12: Twin 200Mm Outlet Installation Example
4. Installation Twin 200mm Outlet Installation Example (3200 Kit required) This is for use where one motor is to be used and there are two 200mm outlets. 3200 motor Ensure flexible ducting is fully extended and as short as possible. Use smooth flowing curves for maximum air flow. -
Page 13: Measurements
5. Measurements Measurements for Isodrive 3200 (Not to Scale) Dimensions in mm Isodrive 3200 weighs 8.3 kg without the PVC pipe. 250.5 Figure 3 Page 13... -
Page 14: Flexible Duct Flexible Ducting
Call outs relating to incorrect installation will result in a service fee directed to the customer. Schweigen will take no responsibility for problems caused by faulty installation. A list of preferred Schweigen installers can be obtained from the Schweigen website www.schweigen.com.au. -
Page 15: Shallow Roof Space
6. Flexible Duct Shallow Roof Space In shallow roof spaces, do not crush or kink flexible ducting, as it will reduce air flow severely. 90 degree curve made of PVC or galvanise can be used as a substitute for the bend, refer to figure 5. 90 degree curve PVC or galvanise curve Figure 5... -
Page 16: Securing Flexible Duct
6. Flexible Duct Securing Flexible Duct Flexible duct must be installed with supports at maximum intervals of 1.5 metres. Flexible ductwork can be supported by using gaffer or electrical tape. Provided that it does not restrict the internal diameter of the ducting. Ducting installed looped over hanging beams should be installed in such a manner as to ensure the changes of direction are gradual. -
Page 17: Parts List
7. Parts List Parts List for Isodrive 3200 Parts List (Isodrive 3200 Figure 8 Page 17... - Page 18 7. Parts List Parts List for Isodrive 3200 Number Part Number Description Quantity P1114 Capacitor 4µF P1123 No.6 X 1 ¼ “ S/T Screw Pan Head P40112 Terminal Box – Box Base and Lid P807 Terminal Block P1122 No.6 X ¾ “ S/T Screw Pan Head...
-
Page 19: Maintenance
All information supplied is to be used for general reference purposes only and is on the understanding that Schweigen Home Appliances will not be liable for any loss, liability or damage of whatever kind arising as a result of any reliance upon such information. - Page 20 HOME APPLIANCES Unit 102/45 Gilby Road, Distributed by: Mt Waverley 3149 Victoria. 1300 881 693 (EST) www.schweigen.com.au...
