- Page 1 INSTALLATION GUIDE ISODRIVE MOTOR S1 - 650m www.schweigen.co.nz...
-
Page 2: Welcome
Welcome Thank you for purchasing your new Schweigen Isodrive system. To get the maximum output from this unit, please read through this guide before use and installation. This guide contains important information on the correct use and maintenance of the unit, as well as important safety notes. -
Page 3: Table Of Contents
Index 1. Welcome _____________________________________________________________________________________ 2 2. Your Safety Before Installation ______________________________________________________________________________ 4 Electrical Cord __________________________________________________________________________________ 4 Motor Features ________________________________________________________________________________ 5 General Notes on Installation and Use ____________________________________________________________ 5 Recommended Installation Distance _____________________________________________________________ 5 Minimum Mounting Height ______________________________________________________________________ 6 Avoidance of Back Flow _________________________________________________________________________ 6 Safety of Children ______________________________________________________________________________ 6 Replacement of Supply Cord _____________________________________________________________________ 6 Why Flexi-duct _________________________________________________________________________________ 6... -
Page 4: Your Safety
It is dangerous to modify any part of this appliance. Modification of any kind, will immediately void the warranty. Do not install Isodrive motor to a non-Schweigen and/or non-silent rangehood. If you fail to do so, your warranty will be voided. -
Page 5: Motor Features
2. Your Safety This guide is for the installation of the motor used in the Isodrive systems after the canopy/rangehood or bathroom extraction grill has been mounted on the wall or ceiling. (Refer to canopy/rangehood or bathroom extraction unit installation manual). NOTE: All PVC pipe and flexi ducting measurements are referring to inside measurements, unless otherwise mentioned. -
Page 6: Minimum Mounting Height
Any installation problem must be reported to Schweigen. Call outs relating to incorrect installation will result in a service fee direct to the customer. Schweigen takes no responsibility for problems caused by faulty installation and may void warranty. A preferred installer list can be obtained from Schweigen website www.schweigen.com.au or... -
Page 7: Description
3. Description Isodrive Motor Included in the box: 1. Isodrive 650 motor (280W x 200H mm approx.) Approx. 3 metre, 10amp cable and standard male plug 2. Fire resistant 100mm (110mm OD ) PVC riser pipe Note: Cable cut-out at the bottom end only 3. -
Page 8: Installation
4. Installation Roof Mount Option Ensure clearance Mounting Flange 100 — 400 100mm PVC Pipe Dektite Eaves Mount Option Bell-mouth adaptor Connect to rangehoood Slot option Connect to rangehood Min 90mm long PVC pipe Bell-mouth adaptor To fan Electrical connection between rangehood and remote fan module Wall Mount Option... -
Page 9: Roof Installation
4. Installation Roof Installation (Recommended duct length: 3 metre) Mount the 100mm rigid PVC pipe securely to the beams, trusses or other appropriate structures, refer figure 1. The pipe should be mounted either vertical or perpendicular to the roof cladding with the roof penetration being sealed using a Dektite or other sealing device. - Page 10 4. Installation Roof Installation Locking Screw Fan Module Roof Clading Mounting Flange Dektite Slot option Roof Frame Optional 100mm PVC Pipe bend Secure pipe to structure Slot pipe for power cord exit. Cover with ducting 150mm flexible ducting tape if required 5 metre max Bell-mouth adaptor Connect to...
-
Page 11: Eaves Installation
4. Installation Eaves Installation After ensuring sufficient clearance exists for the mounting flange and ducting, refer figure 1, cut a circular hole 165mm Ø, maintaining adequate clearances. The eaves sheeting should be reinforced. Pre-drill mounting flange recess. Refer figure 3. If access to the eaves space is restricted, before fixing mounting flange to eaves, preassemble mounting flange, PVC pipe, bell-mouth adaptor and flexi-duct then feed up into roof space. -
Page 12: Wall Installation
4. Installation Wall Installation The installation should be similar to eaves mounting if access to the inside is limited, but if unrestricted. Refer to EAVES INSTALLATION and figure 4. Min 90mm long PVC pipe Min 20mm Bell-mouth Adaptor Flexible 150mm ducting NOTE: Ensure that power cord is feed through exit slot and is not allowed to double back restricting fan inlet. -
Page 13: Back Draft Shutter System
5. Back Draft Shutter System Back Draft Shutter System for 150mm Ducting This back draft shutter suitable for Isodrive 650 motor only. Flexi duct To fan Use duct tape to secure flexi duct to shutter system Direction of In line shutter system airflow Flexi duct Mount shutter system as close to... -
Page 14: Installation For Back Draft Shutter System (150Mm Ducting)
5. Back Draft Shutter System Installation Example for Back Draft Shutter System (150mm Ducting, refer to figure 5) This back draft shutter suitable for Isodrive 650 motor only. Vertical Installation Horizontal Installation Figure 6 shows an example of vertical If you have a narrow roof space, you can install installation. -
Page 15: Back Draft Shutter System Fitment To Bell-Mouth Adaptor
5. Back Draft Shutter System Back Draft Shutter System Fitment to Bell-mouth Adaptor This back draft shutter suitable for Isodrive 650 motor only. This back draft shutter system cannot be installed in eave type installation. Back draft shutter system Bell-mouth adaptor 100mm pipe IMPORANT to fan... -
Page 16: Installation Examples
6. Installation Examples Single Motor Installation Example Use smooth flowing curves for maximum airflow. Remove excess ducting by trimming to length. DO NOT install motor in straight line to rangehood. Connect to rangehood Connect to motor Connect to main power Use reducer 150mm to 200mm Cover Figure 10... -
Page 17: Twin Motor Installation Example
6. Installation Examples Twin Motor Installation Example Where two motors are to be used, follow the below methods for each motor then join into the “Y” piece prior to joining ducting to the canopy / rangehood. Refer figure 11. The two motors can be wired by one of the following methods: •... -
Page 18: Measurements
7. Measurements Measurements for Isodrive 650 278mm 157mm 28mm 195mm 35mm 29mm 35mm minimum 110mm 370mm Figure 12 Page 18... -
Page 19: Flexible Duct
Call outs relating to incorrect installation will result in a service fee directed to the customer. Schweigen will take no responsibility for problems caused by faulty installation. Installation should be done by a qualified technician. A preferred installer list can be obtained from Schweigen website www.schweigen.com.au. -
Page 20: Shallow Roof Space
8. Flexible Duct Shallow Roof Space In shallow roof spaces, do not crush or kink flexible ducting, as it will reduce air flow severely. 90 degree curve PVC or galvanise curve can be used as a substitute for the bend, refer to figure 14. 90 degree curve PVC or galvanise curve Figure 14... -
Page 21: Securing Flexible Duct
8. Flexible Duct Securing Flexible Duct Flexible duct must be installed with supports at maximum intervals of 1.5 metres. Flexible ductwork can be supported by using gaffer or electrical tape. Provided that it does not restrict the internal diameter of the ducting. -
Page 22: Maintenance
9. Maintenance Roof Restoration or Cleaning Before doing your roof restoration or cleaning, please completely cover the outside motor system and avoid all chemical contact. IMPORANT Any damages caused by the use of chemical products are not covered by warranty. Figure 17 Avoid chemical contacted to motor system Page 22... -
Page 23: Warranty/Disclaimer
All information supplied is to be used for general reference purposes only and is on the understanding that Schweigen Home Appliances will not be liable for any loss, liability or damage of whatever kind arising as a result of any reliance upon such information. All pictures used in the guide are for illustrative purposes only. - Page 24 New Zealand 5 Tolich Place, Henderson, Auckland 0610. Phone 0800 200 510 Email info.parex@emerson.com Web www.parex.co.nz Distributed by Axis Group International Pty Ltd. ACN 124 141 322...
