Summary of Contents for Voltex V-3-SW-R10
- Page 1 smart control. TOUCH TOUCH smart life. TRIPLE Switch Smart Touch devices must be Year installed by a qualified Warranty electrical expert.
- Page 2 Versatility is the key to bringing your home to life. Instantly make your home a smart home with our wirelessly brilliant technology! The Voltex Smart Touch Triple Switch, enables scheduled switching, as well as the creation of unique customised scenarios from the comfort of your home or directly from your smart device when you are not homebound.
-
Page 3: Technical Specifications
Technical Specifications: NAME V-3-SW-SSR-3A V-3-SW-R10 PRODUCT CODE A12744 A12745 POWER 100V-230V, 50-60 Hz 100V-230V, 50-60 Hz 3A, for all the buttons, 7A, for all the buttons, MAX. CURRENT (3A Dimmer) (2A Dimmer) LOAD RANGE 6VA-400VA 6VA-1600VA TRANSMISSION 433 MHz 433 MHz... -
Page 4: Getting Started
Getting started: Download the App Install the Switch Sync the Switch to your Central Unit and Mobile App Download the App Scan the QR code Search for the App in your Google Play Store or Apple App Store For the initial installation, your smartphone must be connected to the same Wi-Fi network as the Central Unit! -
Page 5: Install The Switch
Install the Switch Installation Instructions – 1-Way • Connect the Live into LIN and the return or lamp to L1, L2 & L3 N (optional)* 3-SW-SSR (fuse) Phase return to the light fitting *If there is a neutral wire is present, we recommend to connect it to N. - Page 6 To control another light switch as a 2-Way switch, make sure that on the other switch there is a Voltex Smart Touch module. Select one of the buttons that has no wiring connected behind it and when pairing it to the mobile application select 2-Way switch.
- Page 7 Sync the Switch to your Central Unit and Mobile App How to pair your switch to the Central Unit (CU) and your App: • Open the App. • The App identifies the Central Unit and starts the registration process. • For registration, enter your name and email address.
- Page 8 • Pair the switches one at a time by pressing “EDIT”, in the App and then “+” and then “ADD SWITCH”. • Press the circle of the switch for 6 seconds until the switch circle blinks to indicate that pairing has started.
- Page 9 • Follow the on-screen instructions to specify the switch name, switch room and switch icon. • The switch can be tested, before moving onto the next switch. Please note that this process will only set up the one button on the switch. Please follow the same process for the other two buttons to be set up.
- Page 10 • To add timers press “EDIT”, select the required switch icon, then select TIMERS tab. Set the times you require and press “SAVE” to finish. Use the blue tick mark to select which timers you want to temporarily deactivate. Timers can be added on individual switches, on sockets and on scenarios.
- Page 11 We hope you enjoy having smart control of your smart life! If you have any product related queries, don’t hesitate to contact us. www.voltex.co.za/smarttouch smartcontrol@voltex.co.za For full terms and conditions visit www.voltex.co.za/smarttouch...
