Voltex CUBO PSF12W Instruction Manual

TECHNICAL SPECIFICATION
NEUTRAL BARS
PRODUCT SUPPLIED NEUTRAL BARS
PSF12W (2x(35mm²)+8x(16mm²)) + 2x[4x(16mm
PSF18W (2x(35mm²)+8x(16mm²)) + 3x[4x(16mm
PSF24W 2 x [(2x(35mm²)+8x(16mm²)) + 2x[4x(16mm
PSF36W 2 x [(2x(35mm²)+8x(16mm²)) + 3x[4x(16mm
Rated Current of Earth and Neutral Bars = 125A
EARTH BARS
SUPPLIED EARTH BARS
2 )] 2x(35mm²)+10x(16mm²)
2 )] 2x(35mm²)+16x(16mm²)
)] 2 x [2x(35mm²)+10x(16mm²)]
2
2 )] 2 x [2x(35mm²)+16x(16mm²)]
© Voltex Electrical 2020. All Rights Reserved.
®
INSTRUCTION GUIDE
ITEMS INCLUDED
Front Cover and Door
PRODUCT
Base Assembly
Assembly
PSF12W 1 1
PSF18W 1 1
PSF24W 1 1
PSF36W 1 1
CHANGING DOOR ORIENTATION
AU
© Voltex Electrical 2020. All Rights Reserved.
Flush Mount Switchboard IP40
PSF12W, PSF18W, PSF24W, PSF36W
Module Spare
Pole Filler Set Sticker Label Set
Identification Label brackets
1 1 1
1 1 1
2 1 2
3 1 2
P: 1300 722 275 P: 0800 55 66 33
NZ
E: sales@voltexelectrical.com.au E: sales@voltexelectrical.co.nz
www.voltexelectrical.com.au
www.voltexelectrical.co.nz
1
1
1
1
