Digi Connect Tank v2 Quick Start Manual

1

Verify the hardware

If any item is missing or damaged, please contact your supplier. Note any damage that may have occurred during shipping and report it to the supplier.
2

Assemble the device

a Use a 9/64-inch or 3.5 mm hex key to loosen the four retaining
screws and open the Connect Tank enclosure cover.
Insert the SIM.
b
Note: Get an activated SIM card (standard size) from your
cellular service provider.
Unlock the SIM card tray by gently pushing the metal
1
bar toward the bottom of the tray and pulling it open.
Insert the SIM card with the metal contacts face down
2
and the flat edge inserted into the holder.
Press the SIM card tray onto the board and close it by
3
gently pushing the metal bar toward the top of the
SIM card holder.
c
Connect the battery. Make sure the battery and its wiring
are properly placed.
(Optional) Attach a 1-inch to 2-inch adapter to the bottom
d
of the device if your tank has a 2-inch NPT threaded opening.
e
Before you close the device, complete initial configuration
using the command line interface (CLI); see step 3.
Digi Connect Tank v2
with four retaining screws
Battery
Quick Start Guide
Digi Connect Tank v2
90001471 B
Optional parts available through Digi:
Magnet 1-inch to 2-inch
a
b
c
d
NPT adapter
