Ronda Startech 5040.B User Manual

RONDA startech – Movement Cal. 5040.B
User's Manual English
You have decided to buy a watch, which was assembled by a watch-
maker using a Ronda movement. Please note that no watches are
produced or distributed under the Ronda Brand.
In case of repairs, guarantee claims and questions concerning
the functioning of a watch, purchasers and consumers should
contact their retailer or the watch manufacturer, for which the
relevant information can be found in the sales or guarantee
documentation provided with the watch.
Description of the display and control buttons
Display elements
Date
Second hand
Minute hand
Hour hand
Second counter
Minute counter
1
⁄
second counter
10
(running for the first 30 sec.)
Hour counter after 30 min.
01
A
2 3
I II III
B
A
2 3
I II III
B
02
A
3 1
I II
B
A
0 1
I II
B
03
A
1 7
I II
B
A
0 3
I II
B
A
0 3
I II III
B
A
0 4
I II III
B
04
Control buttons
2 3
Push button A
Crown
Push button B

Setting the time

* Pull out the crown to position III
(the watch stops).
Turn the crown until you reach the correct
time 8:45.
* Push the crown back into position I.
Please note:
* In order to set the time to the exact second,
must be pulled out when the second hand
is in position «60».
Once the hour and minute hands have been
set, must be pushed back into position I at
the exact second.

Setting the date (quick mode)

Pull out the crown to position II (the watch
continues to run).
Turn the crown until the correct date
appears.
Push the crown back into position I.
Please note:
During the date changing phase between
approx. 9 PM and 12 PM; the date must be
set to the date of the following day.
An extreme acceleration in setting the date
with quick mode can induce a false date indi-
cation. The synchronization is re-established
by setting the date from 01 till 31 (crown in
position II).
Setting the date/time
following a battery change
Example:
– Date / time on the watch: / 1:25 AM
17
– Present date / time: / 8:30 PM
04
Pull out the crown to position II
(the watch continues to run).
Turn the crown until yesterday's
date appears .
03
**
Pull out the crown to position III
(the watch stops).
Turn the crown until the correct dat
appears.
**
Continue to turn the crown until the
correct time 8:30 PM appears.
**
Push the crown back into position I.
Please note:
*
* To set your watch to the exact second,
please refer to the chapter entitled «setting
the time».
** Please observe the AM/PM clock rhythm.
2 3
2 3
05
2 3
2 3
06
2 3
2 3
07
2 3
01
2 3
A
B
A
B
A
I II
08
04
Battery type: 395 / SR927SW
Accuracy: +20 / -10 seconds per month
Chronograph: Basic function
A
(Start / Stop / Reset)
Example:
Start: Press push-button A.
Stop: to stop the timing, press push-
button A once more and read the
chronograph hands:
B
A
Zero positioning:
Press push-button B.
(The chronograph hands will be reset
to their zero positions.) .
B
Chronograph:
A
Accumulated timing
Example:
Start: (start timing)
Stop: (e.g. 15 min 5 sec following
Restart: (timing is resumed)
*
Stop: (e.g. 5 min 12 sec following
B
=
(The accumulated measured time is shown)
A
Reset:
The chronograph hands are returned
to their zero positions.
Please note:
* Following , the accumulation of the
timing can be continued by pressing push-
button A
B (Restart / Stop, Restart / Stop, ...).
Chronograph:
A
Intermediate or interval timing
Example:
Start: (start timing)
Display interval:
e.g. 20 minutes 17 seconds
continues in the background)
*
Making up the measured time:
B
(The chronograph hands are quickliy
advanced to the ongoing measured time.)
Stop: (Final time is displayed)
A
Reset:
The chronograph hands are returned to
their zero position.
Please note:
* Following , further intervals or inter-
mediates can be displayed by pressing
push-button B (display interval / make up
B
measured time, ...).
Adjusting the chronograph
A
hands to zero position
Example:
One or several chronograph hands are not in
their correct zero positions and have to be
adjusted (e.g. following a battery change).
I II III
Pull out the crown to position III (all
chronograph hands are in their correct or
B
incorrect zero position).
A
Keep push-buttons A and B depressed
simultaneously for at least 2 seconds
(the second counter hand 360°
mode is activated).
III
B
Adjusting the second counter hand
Single step A
Continuous A
Adjusting the next hand B
Adjusting the 1 ⁄ second counter hand (position 6h)
10
Single step
A
Continuous A
Adjusting the next hand B
Adjusting the minute counter hand (position 9h)
Single step A
Continuous A
Returning the crown to position I
III
Termination of the chronograph hands adjustment
(can be carried out at any time).
4min/38sec / ⁄ sec
7
10
)
)
20 min 17 sec
(timing
corrective
1 x short
long
1 x short
long
1 x short
long
07 / 2017
