INSTALLATION INSTRUCTIONS
AMAZON BASIN
EC201S & EC201B
NO PART OF THIS MANUAL OR DOCUMENT MAY BE COPIED OR RE-PRODUCED IN ANY FORM OR BY ANY MEANS WITH OUT THE EXPRESS
WRITTEN PERMISSION OF SMP (PLAYGROUNDS) LTD.
- W: smp.co.uk -
T: +44(0)845 260 1655
E: sales@smp.co.uk

Advertisement

loading
Need help?

Need help?

Do you have a question about the AMAZON BASIN EC201S and is the answer not in the manual?

Questions and answers

Related Manuals for SMP AMAZON BASIN EC201S

Summary of Contents for SMP AMAZON BASIN EC201S

  • Page 1 EC201S & EC201B NO PART OF THIS MANUAL OR DOCUMENT MAY BE COPIED OR RE-PRODUCED IN ANY FORM OR BY ANY MEANS WITH OUT THE EXPRESS WRITTEN PERMISSION OF SMP (PLAYGROUNDS) LTD. - W: smp.co.uk - T: +44(0)845 260 1655...
  • Page 2 AMAZON BASIN EC201 Page 2 ISSUE C 10-05-2012...
  • Page 3 AMAZON BASIN EC201 Section 1: x 2 = T EC201S 311.00 0.44 5.02 X 0.58 X 3.03 6.00 X 1.00 0.60m T = 3h EC201B 323.00 0.48 TYPE 1/2/3 101/144 0.60 m 8020 1500R 1500R 1500R 1500R 1500R 1500R 1500R 1500R 1625 ISSUE C 10-05-2012...
  • Page 4 AMAZON BASIN EC201 EC201B TYPE 1/2 101/144 0.60 m 1 LTB21 4770 450 x 450 450 x 450 400 x 400 400 x 400 Section 1 Page 4 ISSUE C 10-05-2012...
  • Page 5 AMAZON BASIN EC201 EC201S TYPE 3 101/144 0.60 m 1 LTB21 4770 450 x 450 450 x 450 400 x 400 400 X 400 ISSUE C 10-05-2012 Section 1 Page 5...
  • Page 6 AMAZON BASIN EC201 ITEM EC201S EC201B 75.00 4130 LTB21 X 2 781-003 76.00 4920 LTB22 X 1 780-509 17.0 RTB9 782-001 21.30 RYBL400 15.5 780-593 0.40 780-594 0.003 780-595 0.02 780-576 0.40 Section 1 Page 6 ISSUE C 10-05-2012...
  • Page 7 AMAZON BASIN EC201 ITEM EC201S EC201B 803704 6.00 305802 10231040 0.05 10261000 0.01 10381600 0.007 10321600 0.031 786-904 0.03 782-000 0.05 10051025 0.03 RYADHBK Aro-Seal 1132 Polyurethane Sealant http://www.alansonsuk.com/downloads.asp 10120400 ISSUE C 10-05-2012 Section 1 Page 7...
  • Page 8 AMAZON BASIN EC201 STEP 1 1 LTB21 1 LTB21 Section 1 Page 8 ISSUE C 10-05-2012...
  • Page 9 AMAZON BASIN EC201 STEP 2 1 LTB22 1 LTB21 1 LTB21 4&5 1 LTB22 1 LTB21 ISSUE C 10-05-2012 Section 1 Page 9...
  • Page 10 AMAZON BASIN EC201 STEP 3A - EC201B TYPE 1/2 4770 CRS REF STEP 3B - EC201S TYPE 3 4770 CRS REF Section 1 Page 10 ISSUE C 10-05-2012...
  • Page 11 AMAZON BASIN EC201 STEP 4         4&5 ISSUE C 10-05-2012 Section 1 Page 11...
  • Page 12 AMAZON BASIN EC201 STEP 5 1 LTB22 1 LTB21 1 LTB21 STEP 6 Section 1 Page 12 ISSUE C 10-05-2012...
  • Page 13 AMAZON BASIN EC201 STEP 7 ISSUE C 10-05-2012 Section 1 Page 13...
  • Page 14 AMAZON BASIN EC201 STEP 8 Aro-Seal 1132 Polyurethane Sealant Black http:/www.alansonsuk.com/downloads.asp STEP 9 Section 1 Page 14 ISSUE C 10-05-2012...
  • Page 15 AMAZON BASIN EC201 STEP 10 1 LTB21 STEP 11 1 LTB** ISSUE C 10-05-2012 Section 1 Page 15...
  • Page 16 AMAZON BASIN EC201 Section 1 Page 16 ISSUE C 10-05-2012...
  • Page 17 AMAZON BASIN EC201 Appendix A: 782-001 ITEM 782-001 780-560 1.116 RTUBE 780-561 0.432 WAB1 780-568 0.119 780-562 7.00 CA10 780-600 ISSUE C 10-05-2012 Appendix A Page 17...
  • Page 18 AMAZON BASIN EC201 ITEM 782-001 10321000 0.01 10381001 0.011 10321600 0.031 10381600 0.007 STEP 1 Appendix A Page 18 ISSUE C 10-05-2012...
  • Page 19 AMAZON BASIN EC201 STEP 2 ISSUE C 10-05-2012 Appendix A Page 19...
  • Page 20 AMAZON BASIN EC201 Appendix A Page 20 ISSUE C 10-05-2012...
  • Page 21 AMAZON BASIN EC201 Appendix B: 8040 1425 1425 1010 1010 1635 TYPE 1/2 LOOSEFILL 8040 1425 1425 1010 1010 1635 TYPE 3 SYNTHETIC ISSUE C 10-05-2012 Appendix B Page 21...
  • Page 22 AMAZON BASIN EC201 1500 2115 9000 TYPE 5 GRASSMATT FR 1365 7500 TYPE 5 GRASSMATT FR - WEAR AREA Appendix B Page 22 ISSUE C 10-05-2012...

  • Page 23: Specifications

    Suitable working platform to provide secure access and provide support for parts required. SPECIFICATIONS SMP Playgrounds Ltd recommends an effective Impact Absorbing Surface tested to EN1177 & BS7188 beneath this play equipment. Refer to manufacturers instructions for details of installation. The surface should have a Critical Fall Height greater than the Maximum Free Fall Height of the equipment.
  • Page 24 AMAZON BASIN EC201 MARK OUT HOLES Consult SMP layout drawing for structure position on site. See page 4 & 5 for concrete foundation sizes. NOTE: This is a minimum guide only. ESTABLISH DATUM LEVEL If a rubber tiled Impact Absorbing surface is to be laid, see separate instructions (base may incorporate up to 2% falls etc).

  • Page 25: Post Installation Inspection

    AMAZON BASIN EC201 If installation is with a loose fill type (type 1/2) surface, the upright posts should be marked with ‘Basic level mark’ to indicate the recommended finished surface level. (SEE PAGE 4). Remove any installation aids before fitting rope. Fit one end of the Main Support Rope (item 2) to one of the BTN 135 Bolts (item 5) located at the top of an Upright post (item 1- LTB21), secure using 1 off Pivot Bar (item 7) and M5 X 25 Grub Screw (item 6), utilise 2.5mm AF Allen Key ensuring grub screw goes fully into hole of pivot bar to full depth of BTN fitting.
  • Page 26 AMAZON BASIN EC201 Appendix B Page 26 ISSUE C 10-05-2012...

This manual is also suitable for:

Amazon basin ec201b
