EXPLODED VIEW/PARTS LIST

Key Part
No. Number
1 678018001
2 638017001
3 638006005
4 678011001
5 660887001
6 678263001
7 678262001
8 940657011
9 940726004
10 308734001
11 561382001
12 678260001
13 678017001
14 308485001
15 308484001
16 678258001
17 308730001
18 678259001
19 660737001
20 638245001
21 518377001
22 308483001
23 660641001
24 660642001
25 308210001
26 308735001
27 940657007
28 940654019
29 518019001
30 678020001
983000931
Description
Blade Nut (M8) ......................................................................................1
Cupped Washer ....................................................................................1
Blade .....................................................................................................1
Flange Washer ......................................................................................1
* Screw (10-24 x 5/8 in. Hex Hd.) ...........................................................3
* Lock Washer (5 mm) .............................................................................3
Flange ...................................................................................................1
Warning Decal ......................................................................................1
Expand-it Logo Label ...........................................................................1
Blade Guard (Includes Key Nos. 8-9) .................................................1
Debris Flap ...........................................................................................1
Washer (6 mm) .....................................................................................2
* Hex Nut (10-24) .....................................................................................2
Plate with Stud .....................................................................................1
Wheel Arm ............................................................................................1
* Washer (10 mm) ....................................................................................3
Adjusting Knob with Hex Nut ...............................................................1
* Hex Nut with Nylon Cap (5/16-18) ........................................................1
* Hex Screw (10-24 x 1/2 in.) ..................................................................1
Curb Guide ...........................................................................................1
Guide Wheel .........................................................................................1
* Push Nut (10 mm) .................................................................................1
* Hex Screw (10-24 x 5/8 in.) ..................................................................1
* Cap Screw (1/4-20 x 1.25 in.) ...............................................................1
Gear Head Assembly ...........................................................................1
Drive Shaft Assembly (Includes Key Nos. 27-28) ................................1
Warning Decal ......................................................................................1
Warning Label, UL ................................................................................1
Hanger Cap ..........................................................................................1
Holding Pin ...........................................................................................1
Operator's Manual
* STANDARD HARDWARE ITEM — MAY BE PURCHASED LOCALLY
13
Qty.
