  6. Operator's manual

Expand-it UT15518B Operator's Manual

Edger attachment
Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATOR'S MANUAL
Expand-it™
Edger Attachment
UT15518B
Your new Expand-it™ Edger Attachment has been engineered and manufactured to a high standard for dependability, ease of
operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual.
Thank you again for buying an Expand-it™ Accessory.
SAVE THIS MANUAL FOR FUTURE REFERENCE
TM

Advertisement

Table of Contents
loading

Related Manuals for Expand-it UT15518B

Summary of Contents for Expand-it UT15518B

  • Page 1 Expand-it™ Edger Attachment UT15518B Your new Expand-it™ Edger Attachment has been engineered and manufactured to a high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual.

  • Page 2: Table Of Contents

    Maintenance ................................9 - 10 Warranty ..................................11 Parts, Ordering, and Service ............................12 INTRODUCTION With the Expand-it™ Edger Attachment you can create a professionally landscaped look to your lawn. Just connect WARNING: the Expand-it™ Edger Attachment to your attachment Carefully read through this entire operator’s manual...

  • Page 3: Safety Rules

    SAFETY RULES l Always stop the engine and remove the spark plug wire before making any adjustments or repairs except for WARNING: carburetor adjustments. Read and understand all instructions. Failure to follow l Inspect unit before each use for loose fasteners, dam- all instructions listed below, may result in electric shock, aged or missing parts.

  • Page 4: Symbols

    SYMBOLS Important: Some of the following symbols may be used on your unit. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME EXPLANATION Safety Alert Symbol Indicates danger, warning or caution.

  • Page 5: Unpacking

    UNPACKING PACKING LIST INSTRUCTIONS Expand-it™ Edger Attachment (Completely Assembled) We have shipped the Expand-it™ Edger Attachment completely assembled. Hanger Cap l Carefully remove the tool from the box. Make sure that Operator’s Manual all items listed in the packing list are included.

  • Page 6: Features

    FEATURES Before using the Expand-it™ Edger Attachment, familiarize WARNING: yourself with all operating features and safety requirements. Do not allow familiarity with your tool to make you careless. Remember that a careless fraction of a second is sufficient to inflict severe injury.

  • Page 7: Assembly

    ASSEMBLY The edger attachment is fully assembled at the factory and NOTE: If the button does not release completely in the requires no further assembly. positioning hole, the shafts are not locked into place. Slightly rotate from side to side until the button is locked into JOINING THE POWER HEAD TO THE EDGER place.

  • Page 8: Operation

    OPERATION TO ADJUST THE BLADE DEPTH See Figures 4 and 5. WARNING: Depth of the cut is determined by the distance from the Wear safety glasses or goggles when operating this tool. bottom of the wheel to the tip of blade. Failure to do so could result in possible serious injury.

  • Page 9: Maintenance

    MAINTENANCE WARNING: TURN BLADE NUT Use only original manufacturer's replacement parts, ac- CLOCKWISE cessories and attachments. Failure to do so may cause BLADE poor performance, possible injury and may void your warranty. l Never operate a unit that is damaged, improperly ad- justed, or is not completely and securely assembled.
  • Page 10 MAINTENANCE MAINTENANCE STORING THE EDGER ATTACHMENT ATTACHING THE STORAGE HANGER See Figure 8. Store the edger attachment in a well ventilated place that is inaccessible to children. Keep away from corrosive agents There are two ways to hang your attachment for storage. such as garden chemicals and de-icing salts.

  • Page 11: Warranty

    This warranty is limited to ninety (90) days from the date of original DAMAGE TO PERSONAL PROPERLY, LOSS OF REVENUE, LOSS retail purchase for any Expand-it™ product that is used for rental or OF USE OF THE PRODUCT, LOSS OF TIME, OR commercial purposes, or any other income-producing purpose.

  • Page 12: Parts, Ordering, And Service

    UT15518B SERVICE For parts or service, contact your nearest Expand-it™ authorized service center. Be sure to provide all relevant information when you call or visit. For the location of the authorized service center nearest you, please call 1-800-chainsaw (1-800-242-4672) or visit us online at www.homelite.com.
