ADVANCED PROGRAMMING OPTIONS.
Need
Master code - Master code
Enter programming mode
*00 - new master code (4-8 digits) Note the number of digits the master
Change master code
is set to will be the number of digits each user code must be.
Set user codes 01 ~ 19 (Lock output relay
*01~ 19 - new unique user code (Same length as master code)
only)
Set user codes 20 ~ 39 and 41 ~ 99 (lock
*6 - 2 digit user number - new unique user code (Same length as master code)
output relay only)
Set user code 40 (Aux output only) *40 new unique aux user code (Same length as master code)
*20 - 00 = latch mode or 01 sec for 1 sec, 02 for 2 sec
Select Lock relay mode or pulse length.
Activating incorrect code input lockout (20
*51
digits or 5 attempts results 30sec lockout)
Delete a user code or all user codes. (If
*50 - 00 for all, 01 for user 1, 02 for user 2
deleting all user 01 defaults to 3333)
Activating bypass mode. *52 - 1
De-activate bypass mode. *52 - 0
Setup bypass code *54 - new unique bypass code
Disable alarm output mode *55 - 0
Select alarm output activates on door forced
*55 - 1
open condition
Select alarm output activates on tamper
*55 - 2
switch
Select alarm output activates on both door
*55 - 3
forced and tamper switch
*56 - 001 for 1 sec, 002 for 2 sec
Select Alarm output active time
*58 - 00 = latch mode or 001 for 1 sec, 002 for 2 sec
Select Aux ouput mode or pulse length
Disable Aux ouput *57 - 0
Allocate door monitor to work with Aux
*57 - 1
output
Activate Aux output when incorrect code is
*57 - 2
entered
Activate Aux output when * key is pressed
*57 - 3
(Doorbell function)
*57 - 4
Activate Aux output when tamper is activated
*57 - 5
Activate Aux output when door is forced open
Activate Aux out at same as lock output *57 - 6
Aux ouput only activates when Aux code is
*57 - 7
entered
Factory default Power down
Place jumper across restore pins
Power up
On continuous chime remove jumper and replace it in normal operation position.
Action Response
Buzzer
Chime tone
up
No chime
tone
Chime tone
up
Chime tone
up
Chime tone
up
Chime tone
99 for 99 sec
up
Chime tone
up
Chime tone
.99 for user 99.
up
Chime tone
up
Chime tone
up
Chime tone
up
Chime tone
up
Chime tone
up
Chime tone
up
Chime tone
up
Chime tone
..999 for 999 sec.
up
..999 for 999 sec.
Chime tone
up
Chime tone
up
Chime tone
up
Chime tone
up
Chime tone
up
Chime tone
up
Chime tone
up
Chime tone
up
Continuous
chime
4
How to, quickly, setup the keypad for use by up to 20 users.
1. The master code is used to access programming mode. (Default master code = 1234)
The amount of digits used in the master code can be anything between 4 and 8 digits.
LED
NB! The number of digits used for the master code will determine the length of all other codes.
Yellow
I.e. The default master code is 1234 so therefore all user codes will be 4 digits long.
Yellow
Setup a new master code: (Default = 1234)
Yellow
Type in the following:
Current Master Code Current Master Code (chime tone up) *00 New 4 to 8 digit Master Code # (chime
tone down)
I.e. To change the master code to 4321:- 1234 1234 *00 4321 #
Setup user codes 01 to 19 that activate the lock relay: (User 01 default = 3333)
Type in the following:
Master Code Master Code (chime tone up) *two digit user number New User Code (chime tone up)
I.e. To change user 01 to 8282 without exiting program mode afterwards: -
1234 1234 *01 8282
Repeat for additional users or type # to exit programming mode (Chime tone down).
Setup code to activate the Auxiliary relay: (Default none)
Type in the following:
Master Code Master Code (chime tone up) *40 New Auxiliary Code (chime tone up)
I.e. To setup Aux relay code to 2222 without exiting program mode afterwards:-
1234 1234 *40 2222
Continue to additional programming or type # to exit programming mode (Chime tone down).
Deleting a user code:
Type in the following:
Master Code Master Code (chime tone up) *00 # to clear all users and default user 01 to 3333
Or
Master Code Master Code (chime tone up) * 2 digit user number # to clear an individual user.
Setup type or pulse length of Lock relay: (Default = 5 sec.)
Type in the following:
Master Code Master Code (chime tone up) *20 00 for latch mode or 01 sec for 1 sec, 02 for 2
99 for 99 sec # to exit programming mode. (Chime tone down)
sec
