/ E-mail: sales@whr.hk
www.whr.hk
Power Supply丨Access Control丨Exit Button丨Security System丨PA System丨Communication System
Smart Waterproof Keypad with RFID + Fingerprint
Important Notes:
1.
Please read this user manual before use, and keep it for future reference.
2.
Please change the master code and public code regularly, mark down the changes in the
table provided in this user manual, and save for record.
3.
For program manual, read the 'remarks' whenever it's applicable, and follow the instructions
in sequential order.
ELECTRONIC
SECURITY
ELV SOLUTION & SPECIALIST
USER MANUAL
(Please read the user manual before use)
Model：MKP-3800
IoT Digital Keypad Series
MKP-3801, MKP-3802
876-MKP38003-02
Advertisement
Table of Contents
Related Manuals for MiTEC MKP-3800
Summary of Contents for MiTEC MKP-3800
- Page 1 Power Supply丨Access Control丨Exit Button丨Security System丨PA System丨Communication System USER MANUAL (Please read the user manual before use) Smart Waterproof Keypad with RFID + Fingerprint Model：MKP-3800 IoT Digital Keypad Series MKP-3801, MKP-3802 Important Notes: Please read this user manual before use, and keep it for future reference.
-
Page 2: Table Of Contents
Content 1. Packing List................2. Product Overview..............3. Features.................. 4. Specifications ................ 5. Installation................6. Keypad Operation - Program Manual........7. APP Connection and Operation - APP Manual....Function Program Code Factory Default Changes Remarks Master Code 0000 Check Master Card ... -
Page 3: Packing List
1.Packing List Body Assembly *1 Master Card *1 User Card *5 Waterproof Plastic Sheet *1 T20 Key *1 T20 Screw *1 User Manual*1 Warranty Card*1 2.Product Overview REED Input AUX / Doorbell Output Push Button Input Alarm Output E-Lock Output Power Input REED Bypass System Restore... -
Page 4: Features
3.Features Smartphone Cloud Log WiFi 2.4GHz Fingerprint Code & Card Remote Control Access Connection (Android & iOS) Zinc-Alloy Case Touch Keypad LED Keypad Backlight Doorbell Button MIFARE (13.56MHz), FeliCa, NFC 4.Specifications Operating Voltage DC 12-24V ±20% Operating Current Standby: <150mA Max.: <300mA No. -
Page 5: Installation
5.Installation UK Standard Mounting Box US Standard Mounting Box Front View Back View Side View... - Page 6 Wiring - Connect With the Power Supply for E-Lock Terminals Terminal Terminal Function Remark DC Power Input Connect with DC12-24V Power Source 9-30V N.C. Normally Closed Lock Output Connect with a Fail-Safe(N.C.) Lock LOCK COM Common Terminal The Common Terminal for the Lock Output E-Lock Power N.O.
-
Page 7: Keypad Operation - Program Manual
6.Keypad Operation - Program Manual This program manual is an overview for keypad programming setting. In each settings follow the ‘Procedure’, read the ‘Remarks’ is available and input according ‘Key Combination’. - Page 8 *Public code remains after delete all users...
- Page 9 *Public code can stop alarm after normal...
-
Page 10: App Connection And Operation - App Manual
7.APP Connection and Operation - APP Manual APP Download Tuya Smart Smart Life Either Tuya Smart or Smart Life will work perfectly with MKP-3800. - Page 11 Connect MKP-3800 Input CODECODE*8600 0, enter connection. Device will appears automatically, press “Add” to proceed. Enter Wi-Fi Info and connect device to internet. Wait about 1 min and device will add successfully. Reminder for Connection *Make sure the device is powered on and is not registered by other account(s).
- Page 12 APP UI & Control Remote Unlock Control Press and hold the unlock button will unlock the door remotely, all members have the right to remote unlock. Access Log The latest door access event will show on the main page, press on bring you to the full access log.
- Page 13 Newly added unlock Select all related unlock Choose the member add different unlock methods will methods of one member which all selected unlock methods automatically appears on you are assigning to. methods are belonged (code/fingerprint/card) on member manageme MKP-3800 for members. section.
