NorthStar NS157310 Quick Start Manual

PART NO. NS157310
NorthStar 3000PSI Hot/Cold Water
Petrol Pressure Washer
THESE INSTRUCTIONS ARE TO BE USED AS A GUIDE ONLY AND ARE NOT INTENDED TO REPLACE THE FULL INSTRUCTION MANUAL PROVIDED WITH YOUR PRODUCT.
ALWAYS READ THE INSTRUCTION MANUAL FOR FULL DETAILS RELATING TO SAFETY INSTRUCTIONS, ASSEMBLY, OPERATION AND MAINTENANCE OF YOUR PRODUCT.
ALWAYS MAKE SURE YOUR PRESSURE WASHER IS ON STABLE LEVEL GROUND BEFORE CHECKING OIL LEVELS.
1
Fully unpack the contents of the
pressure washer and lay out all
accessories .
4
Assemble the Right handle using the
bolts & nuts supplied. Assemble the
L/H handle using the hose holder
bracket & nuts supplied.
7
Using a funnel, empty the entire
contents of the 2 bottles of engine oil
supplied with the product into the
motor crankcase, through the
dipstick hole. Check the oil level
before use.
Have questions relating to assembly or operation of your product, call KINCROME on
2
Remove the instruction manuals that
are located within the product battery
box. then read all safety & user
instructions carefully. Note: There are
two separate instruction manuals. One
for the motor & one for the pressure
washer.
5
With the assistance of a second
person, locate and install the wheels
onto the axles with the securing lock
rings. Use an Allen key to tighten the
locking ring fasteners.
8
Connect the RED ended cable to the
Positive (+) battery post & connect the
BLACK ended cable to the Negative (-)
battery post. Ensure the cable
connections are tight. Then place &
secure the battery into the battery box.
3
Remove all product components &
review the instruction manual to
confirm all components have been
supplied with the product.
6
Check and verify the pressure pumps oil level
by visually inspecting the pumps oil level sight
glass. Verify that the oil level is at least ½ way
up the sight glass & then remove the shipping
tape from the RED breather plug.
9
Fill both fuel tanks located on the top of
the pressure washer, making sure you
put the correct fuel type into the
relevant fuel tank. Red tank- Unleaded
Petrol for Motor, Yellow tank- Diesel or
Kerosene Fuel for the heating burner.
1300 657 528
